Package Contents
1
Wireless Access Point
2
Faceplate Cover
3
Cross-head Screw
4
This Quick Start Guide
Before You Begin
Before you begin the installation, make sure that you have the following tools:
Common Tools
Phillips screwdriver, related copper and fiber cables, bolts, diagonal pliers, cable ties
Special Tools
Wire stripper, crimping pliers, RJ-45 crimping pliers, punch down tool
Meter
Multimeter, bit error rate tester (BERT)
The listed tools are customer supplied.
LED and Reset Button
LED/Button
Frequency
Fast blinking (2.5Hz)
Solid
System
Double blinking (1Hz)
(Blue)
Single blinking (1Hz)
Slow blinking (0.4Hz )
Pressed for less than 1s
Reset Button
Pressed for more than 5s Restores all default settings.
Mounting the Access Point
Meaning
Initialization is in progress.
AP is operational and CAPWAP connection is established. No client
is associated.
Ethernet link is down.
Ethernet link is up. No CAPWAP connection is established.
AP is operational and CAPWAP connection is established. At least
one client is associated.
Restarts the device.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ruijie RG-AP110-L
Summary of Contents for Ruijie RG-AP110-L
- Page 1 Package Contents Wireless Access Point Faceplate Cover Cross-head Screw This Quick Start Guide Before You Begin Before you begin the installation, make sure that you have the following tools: Common Tools Phillips screwdriver, related copper and fiber cables, bolts, diagonal pliers, cable ties Special Tools Wire stripper, crimping pliers, RJ-45 crimping pliers, punch down tool Meter...
- Page 2 You need to buy the RG-AP100-MNT mounting bracket, if you mount the AP on an outlet box compliant with US or EU standards. Powering the Access Point The access point supports two power supply modes. The following examples illustrate how to power on and connect to the access point.
- Page 3 Configuring the Access Point Part1: Sign up your Ruijie Cloud account Step1-1: If you do not have a Ruijie Cloud account, you can register on Ruijie Cloud App (download in Google Play) or on https://cloud.ruijienetworks.com. Step1-2: Tap Sign Up to register an account.
- Page 4 (QR code on the rear of the access point). Step2-5: Now you can connect to the WiFi and log in to Ruijie Cloud (https://cloud.ruijienetworks.com) to complete advanced configuration. For more information, please scan the QR code or visit https://ruijienetworks.com/support/documents/wireless.
- Page 5 For further information, please visit our website: http://www.ruijienetworks.com. Copyright © 2019. Ruijie Networks Co., Ltd. All rights reserved. Ruijie Networks reserves the rights to change, modify, transfer, or otherwise revise this publication without notice, and the latest version of this publication shall be applicable.
