Led Indicators; Power Sources - Ruijie RG-AP710 Series Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
2. Console port
3. Reset button

1.3 LED Indicators

Fit AP
State Frequency
Off N/A
Blinking green 3Hz
Solid green N/A
Blinking red 3Hz
Solid orange N/A
Blinking orange 3Hz
Solid blue N/A
Blinking blue 3Hz
Pressed for less
than 2s
Reset button
Pressed for more
than 3s
Fat AP
State Frequency
Off N/A
Blinking green 3Hz
Solid green N/A
Blinking red 3Hz
Solid blue N/A
Blinking blue 3Hz
Pressed for less
than 2s
Reset button
Pressed for more
than 3s

1.4 Power Sources

The AP can be powered either with a DC power adapter or through Power over Ethernet (PoE).
5. LAN1/PoE port
6. 5V DC power supply input port
Meaning
The AP is NOT receiving power. Or the AP is in Do Not Disturb mode, which
can be disabled by software.
uBoot program initialization in progress
Main program initialization in progress
Initialization is complete, but no Ethernet activity.
Initialization is complete, and the AP is establishing a CAPWAP connection
with an AC.
Firmware upgrade in progress. Do not power off.
Normal operation, but no wireless clients are associated with the AP.
Normal operation, at least one wireless client is associated with the AP.
Restart the device.
Restore default settings.
Meaning
The AP is NOT receiving power. Or the AP is in Do Not Disturb mode, which
can be disabled by software.
uBoot program initialization in progress
Main program initialization in progress
Initialization is complete, but no Ethernet activity.
Normal operation, but no wireless clients are associated with the AP.
Normal operation, at least one wireless client is associated with the AP.
Restart the device.
Restore default settings.
Product Overview
