BlackDiamond 10808 Switch

Hardware Installation Guide

Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
(888) 257-3000
(408) 579-2800
http://www.extremenetworks.com
Published: April 2008
Part number: 100285-00 Rev. 01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BlackDiamond 10808 and is the answer not in the manual?

Questions and answers

Related Manuals for Extreme Networks BlackDiamond 10808

Summary of Contents for Extreme Networks BlackDiamond 10808

  • Page 1: Blackdiamond 10808 Switch

    BlackDiamond 10808 Switch Hardware Installation Guide Extreme Networks, Inc. 3585 Monroe Street Santa Clara, California 95051 (888) 257-3000 (408) 579-2800 http://www.extremenetworks.com Published: April 2008 Part number: 100285-00 Rev. 01...
  • Page 2 ServiceWatch, Summit, SummitStack, Triumph, Unified Access Architecture, Unified Access RF Manager, UniStack, the Extreme Networks logo, the Alpine logo, the BlackDiamond logo, the Extreme Turbodrive logo, the Summit logos, the Powered by ExtremeXOS logo, and the Color Purple, among others, are trademarks or registered trademarks of Extreme Networks, Inc.

  • Page 3: Table Of Contents

    SFP Ports ...28 10G2H LEDs ...28 I/O Module LEDs ...29 Chapter 3: Power Supply Units for the BlackDiamond 10808 Switch ... 31 Overview of BlackDiamond 10808 Power Supplies ...31 Extreme Networks 700/1200 W AC PSU ...31 BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 4 Selecting a UPS ...53 Calculating Volt-Amperage Requirements...53 UPS Transition Time ...54 Applicable Industry Standards...54 Chapter 5: Installing a BlackDiamond 10808 Chassis ... 55 Required Tools and Resources...56 Unpacking the Chassis ...56 Checking the Shipping Status Indicators ...56 Removing the Accessories Box...58 Removing the Carton from the Chassis ...60...
  • Page 5 Installing an Extreme Networks 700/1200 W AC PSU ...72 Required Tools and Equipment...73 Installing the 700/1200 W AC PSU ...73 Removing or Replacing an Extreme Networks 700/1200 W AC PSU ...74 LEDs on the 700/1200 W AC PSU...75 Power Supply Cords...75 Installing an Extreme Networks 1200 W DC PSU ...76...
  • Page 6 Table of Contents Part 4: BlackDiamond Maintenance Procedures Chapter 9: Replacing BlackDiamond 10808 Switch Chassis Components ... 107 Replacing a BlackDiamond 10808 Switch Fan Tray ...107 Removing the Fan Tray ...107 Installing the Replacement Fan Tray ...108 Replacing the BlackDiamond 10808 Air Filter ...109 Replacing a BlackDiamond 10808 Power Supply Controller ...110...

  • Page 7: Preface

    Extreme Networks BlackDiamond 10808 switches. NOTE If the information in the installation note or release note shipped with your Extreme Networks switch differs from the information in this guide, follow the installation or release note. BlackDiamond 10808 Switch Hardware Installation Guide of this guide.

  • Page 8: Conventions

    Convention Screen displays The words “enter” and “type” [Key] names Words in italicized type Related Publications The Extreme Networks ExtremeXOS™ switch documentation set includes: ● ExtremeXOS 12.1 Concepts Guide ExtremeXOS 12.1 Command Reference Guide ● ExtremeXOS 12.1 Release Notes ●...
  • Page 9 Documentation for Extreme Networks products is available from the Extreme Networks website at the following location: http://www.extremenetworks.com/services/documentation You can select and download the following Extreme Networks documentation from the Documentation Overview page: Software User Guides ● Hardware User Guides ●...
  • Page 10 Preface BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 11: Part 1: About The Blackdiamond 10808 Switch

    About the BlackDiamond 10808 Switch...

  • Page 13: Chapter 1: Overview Of The Blackdiamond 10808 Switch

    Most ports on an Extreme Networks switch will auto-negotiate duplex in the default configuration. Gigabit Ethernet fiber ports and 10-gigabit Ethernet ports operate only in full-duplex mode in accordance with technical standards.

  • Page 14: Management Ports

    Do not cover or obstruct the fan ventilation holes at the rear of the unit. Doing so can result in overheating and possible damage to the BlackDiamond 10808 switch. Thermal sensors will shut down the BlackDiamond 10808 switch if the internal temperature exceeds 60 degrees Celsius.
  • Page 15 When the BlackDiamond 10808 switch is first powered on, the power supply controllers enable the power supplies by providing 48V power. The power supply controller also detects and reports incompatible combinations of power supply types and line voltage feeds and disables the power supply if an unsafe condition arises.
  • Page 16 Overview of the BlackDiamond 10808 Switch Figure 2 shows the rear panel of the BlackDiamond 10808 switch. Figure 2: Rear View of the BlackDiamond 10808 Switch Fan trays Power supply controllers The rear panel of the BlackDiamond 10808 switch provides: Access to the fan units ●...

  • Page 17: Chapter 2: Blackdiamond 10808 Series Modules

    I/O modules. A BlackDiamond module consists of a printed circuit board mounted on a metal panel that acts as the insertion vehicle in the BlackDiamond 10808 switch. The module carrier also includes ejector/injector levers and captive retaining screws at each end of the module front panel.

  • Page 18: Redundant Msm Activity

    MSM performs a soft reset and then becomes the primary MSM. For example, in a BlackDiamond 10808 switch with a primary MSM in slot A and a backup MSM in slot B, if you remove the primary MSM from slot A, the backup MSM in slot B becomes the primary MSM.

  • Page 19: Msm Leds

    To reset the critical software error LED (amber ERR LED), use the clear log static command and reboot the switch. If you continue to have critical software errors, or the ERR LED is amber after the clear log static command and a switch reboot, contact Extreme Networks Customer Support.

  • Page 20: I/O Modules

    ● NOTE On the BlackDiamond 10808 switch, the 10 Gbps module (10G6X module) must have the serial number 804405- 00-09 or higher to support untagged frames. To display the serial number of the module, use the show slot <slot_number> command. (All the modules on the Black Diamond 8800 series of switches, as well as the Summit X450 switch, support tagged and untagged frames.)

  • Page 21: G60T Module

    The G60T module has 60 autosensing 10/100/1000BASE-T ports that use standard RJ-45 connectors. If one MSM is installed in the switch, all ports on the G60T module are switched through that MSM. If two MSMs are installed, the top 30 ports on the G60T module are switched through the MSM in slot A, and the bottom 30 ports are switched through the MSM in slot B during normal operation.

  • Page 22: G60X Module

    LX mini-GBIC, which conforms to the 1000BASE-LX standard ● ZX mini-GBIC, which conforms to the IEEE 802.3z standard ● NOTE For more information about the supported mini-GBIC types and specifications, see the Extreme Networks Pluggable Interface Modules Installation Guide. EX_005 BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 23: G60X Leds

    The G20X module has 20 unpopulated SFP-based Gigabit Ethernet fiber ports. If one MSM is installed in the switch, all ports on the G20X module are switched through that MSM. If two MSMs are installed, the top 10 ports on the G20X module are switched through the MSM in slot A, and the bottom 10 ports are switched through the MSM in slot B during normal operation.

  • Page 24: Sfp Ports

    ● ZX SFP, which conforms to the IEEE 802.3z standard ● NOTE For more information about the supported mini-GBIC types and specifications, see the Extreme Networks Pluggable Interface Modules Installation Guide. G20X LEDs The G20X module has the following LEDs: Module status ●...

  • Page 25: Xenpak Ports

    If one MSM is installed in the switch, all ports on the 10G6X module are switched through that MSM. If two MSMs are installed, the top three ports on the 10G6X module are switched through the MSM in slot A, and the bottom three ports are switched through the MSM in slot B during normal operation.

  • Page 26: 10G2X Module

    SR XENPAK ● LR XENPAK ● ER XENPAK ● ZR XENPAK ● LX4 XENPAK ● LW XENPAK ● NOTE CX4 XENPAKs are also supported with Extreme Networks devices; contact your vendor to obtain these. BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 27: 10G2X Leds

    For more information about the supported XENPAK types and specifications, see the Extreme Networks Pluggable Interface Modules Installation Guide. 10G2X LEDs The 10G2X module has the following LEDs: Module status ● Port status ● For information about the LEDs and their activity on the 10G2X module, see...

  • Page 28: Xenpak Ports

    LW XENPAK ● NOTE CX4 XENPAKs are also supported with Extreme Networks devices; contact your vendor to obtain these. For more information about the supported XENPAK types and specifications, see the Extreme Networks Pluggable Interface Modules Installation Guide. SFP Ports...

  • Page 29: I/O Module Leds

    I/O Module LEDs Table 4 describes the LED activity on the BlackDiamond 10808 series I/O modules. Table 4: BlackDiamond 10808 Series Ethernet I/O Module LEDs Color Indicates Status Green blinking Normal operation Amber blinking Configuration error, code version error, diagnostic failure, or...
  • Page 30 BlackDiamond 10808 Series Modules BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 31: Chapter 3: Power Supply Units For The Blackdiamond 10808 Switch

    ● Overview of BlackDiamond 10808 Power Supplies The BlackDiamond 10808 switch can be powered by either AC or DC power supplies (PSUs). In an N+1 configuration, power supplies in the BlackDiamond 10808 switch are fully fault tolerant and load-sharing. For a switch using DC power supplies in an N+N configuration, each group of power supplies can provide A/B feed redundancy for the system.

  • Page 32: Leds

    Power Supply Cords Extreme Networks 700/1200 W AC PSUs are shipped with both 110 V AC and 220 V AC power supply cords. The 110 V AC power supply cord allows a maximum DC output power of 700 W. The 220 V AC power supply cord allows a maximum DC output power of 1200 W.

  • Page 33: Fuse

    The wire size must be a minimum of 16 AWG (1.0 mm ● WARNING! Be sure that the source outlet is properly grounded before plugging the AC power cord into the Extreme Networks AC PSU. Fuse The Extreme Networks 700/1200 W AC PSU line and neutral legs are both fused. Power to the switch may still be live if the neutral fuse is open.
  • Page 34 1200 W DC PSU installed in the switch. NOTE Extreme Networks does not recommended combining the 1200 W DC PSU with any Extreme Networks AC PSU in the same BlackDiamond system. Extreme Networks recommends that DC and AC PSU units not be used together in the same BlackDiamond switch.

  • Page 35: Minimum Software Required

    Field operators must not attempt to open the 1200 W DC PSU enclosure for any reason; the PSU does not contain user-serviceable parts. In the event of failure, return the defective 1200 W DC PSU to Extreme Networks for repair or replacement.
  • Page 36 Power Supply Units for the BlackDiamond 10808 Switch BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 37 Installing BlackDiamond 10808 Switches and...
  • Page 38 Modules...

  • Page 39: Chapter 4: Site Preparation

    ● After examining your physical site and ensuring all environment requirements are met, evaluate and compare your existing cable plant with the requirements of the Extreme Networks equipment to determine if you need to install new cables (or cabling). BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 40: Meeting Site Requirements

    The address is NEMA; 1300 N. 17th Street; Rosslyn, Virginia 22209. Electronics Industries Alliance (EIA)—a trade association that develops technical standards, ● disseminates marketing data, and maintains contact with government agencies in matters relating to 135. http://www.nfpa.org BlackDiamond 10808 Switch Hardware Installation Guide “Power Supplies for the http://www.nema.org...

  • Page 41: Wiring Closet Considerations

    Temperature Extreme Networks equipment generates a significant amount of heat. It is essential that you provide a temperature-controlled environment for both performance and safety. Install the equipment only in a temperature- and humidity-controlled indoor area that is free of airborne materials that can conduct electricity.

  • Page 42: Humidity

    To ensure proper airflow through a BlackDiamond switch, refer to the following recommendations when you are installing your switch: BlackDiamond 10808 switches require a minimum of 3 inches (8 cm) around both the front and rear ● of the chassis from any cabinet wall or other obstruction for proper airflow.

  • Page 43: Electrostatic Discharge

    Figure 13: Airflow Through the BlackDiamond 10808 Chassis Airflow through chassis Airflow through power supplies Electrostatic Discharge Your system must be protected from static electricity or electrostatic discharge (ESD). Take the following measures to ensure optimum system performance: Remove materials that can cause electrostatic generation (such as synthetic resins) from the wiring ●...

  • Page 44: Rack Specifications And Recommendations

    Use a rack grounding kit and a ground conductor that is carried back to earth or to another suitable building ground. All Extreme Networks switches are designed with mounting brackets that provide solid metal-to-metal connection to the rack. If you do not use equipment racks, you can attach wiring terminals directly to the mounting brackets for appropriate grounding.

  • Page 45: Space Requirements For The Rack

    WARNING! The chassis does not have a switch for turning power to the unit on and off. For systems using an AC power supply, power to the chassis is disconnected by removing the wall plug from the electrical outlet. For systems using a DC SSI power supply, power to the chassis can be turned off by lifting the handle on the power supply or by de- energizing the circuit that feeds the power supply, which is usually accomplished by turning off a circuit breaker.

  • Page 46: Evaluating And Meeting Cable Requirements

    ● Radio Frequency Interference ● Cabling Standards Extreme Networks recommends using the Building Industry Consulting Service International (BICSI) Registered Communications Distribution Designer (RCDD), which is globally recognized as a standard in site planning and cabling. For information, go to: http://www.bicsi.org Cable Labeling and Record Keeping A reliable cable labeling system is essential when planning and installing a network.

  • Page 47: Installing Cable

    Assign a unique block of sequential numbers to the group of cables that run between each pair of ● wiring closets. Assign a unique identification number to each distribution rack. ● Identify all wiring closets by labeling the front panel of your Extreme Networks equipment and ● other hardware. Keep accurate and current cable identification records. ●...

  • Page 48: Fiber Optic Cable

    Use care in dressing the optical fiber cables: provide satisfactory strain relief to support the cable and maintain an adequate bend radius at all cable turns, particularly where the cable connects to the I/O module. BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 49: Cable Distances

    Category 5 and higher UTP cable 10BASE-T Category 3 and higher UTP cable Proprietary to Extreme Networks. Connections between two Extreme Networks 1000BASE-LX interfaces that use 10/125 μm single-mode fiber can use a maximum distance of 10,000 meters. BlackDiamond 10808 Switch Hardware Installation Guide Evaluating and Meeting Cable Requirements 90∞...

  • Page 50: Rj-45 Connector Jackets

    Figure 18: RJ-45 Connector Jacket Types Not recommended Best 0.1" = 1mm actual Better 39.37% : 254% BlackDiamond 10808 Switch Hardware Installation Guide SPG_001...

  • Page 51: Radio Frequency Interference

    IEEE 802.3af. Power Supply Requirements Adhere to the following requirements to operate your Extreme Networks equipment safely: Be sure that your equipment is placed in an area that accommodates the power consumption and ●...

  • Page 52: Ac Power Cable Requirements

    Site Preparation If a power source fails, it will affect only the switch power supply to which it is connected. If all switch power supplies are connected to a single power source, the entire switch is vulnerable to a power source failure.

  • Page 53: Uninterruptible Power Supply Requirements

    An uninterruptible power supply (UPS) is a device that sits between a power supply (such as a wall outlet) and a device (such as a switch) to prevent outages, sags, surges, and bad harmonics from adversely affecting the performance of the device.

  • Page 54: Ups Transition Time

    UPS Transition Time Transition time is the time that is necessary for the UPS to transfer from utility power to full-load battery power. For Extreme Networks products, a transition time of less than 20 milliseconds is required for optimum performance.

  • Page 55: Chapter 5: Installing A Blackdiamond 10808 Chassis

    Correct lifting procedures for the BlackDiamond 10808 chassis requires two or more people. Before you lift a BlackDiamond 10808 chassis, make sure the chassis is empty to prevent unnecessary weight. This will also prevent damage to the system components due to possible system chassis flex when lifting.

  • Page 56: Required Tools And Resources

    ● Unpacking the Chassis The BlackDiamond 10808 chassis is shipped bolted to a wooden pallet, with a carton fastened over the pallet. An accessory box is inside the top of the carton. To begin the installation process, unpack the accessories and remove the shipping carton from the pallet.
  • Page 57 Each indicator has two color-coded states, or modes: a good, white state, and a warning, red state. A smooth shipping procedure should leave all four indicators in good, white states. Figure 20 shows the tilt watch and shock watch indicators in both conditions. BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 58: Removing The Accessories Box

    CAUTION If either the tilt watch or shock watch indicator shows a red warning condition, do not proceed with unpacking. Contact your shipping company or Extreme Networks and speak to a representative before continuing. Removing the Accessories Box To remove the accessories box from the carton: 1 Cut away the plastic that wraps the carton.
  • Page 59 The accessories box contains: 19-inch helper bracket for installing the chassis in a rack ● ESD-preventive wrist strap ● Front bezel for shielding the switch after installation ● Documentation and media ● BlackDiamond 10808 Switch Hardware Installation Guide EX_085 Unpacking the Chassis...

  • Page 60: Removing The Carton From The Chassis

    Figure 22: V-Boards in the Chassis Carton V-boards 2 Remove the four detachable plastic clip locks near the bottom of the shipping carton, as shown in Figure Two clip locks are located on each side of the carton. Figure EX_093A BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 61 Repeat these steps to release each remaining lock. Figure 24: Removing the Clip Locks Squeeze prongs to unlock Clip lock 3 Slide the carton up over the chassis, as shown in BlackDiamond 10808 Switch Hardware Installation Guide EX_182 Figure 24) to grasp the prongs. Open lock...

  • Page 62: Installing The Chassis

    BlackDiamond 10808 switch. Installing the Chassis The BlackDiamond 10808 switch is shipped with a pre-installed fan tray. For your safety, because of the increased weight of the chassis after components are installed and to prevent damage to the equipment, Extreme Networks strongly recommends that you install the I/O modules after you mount the chassis in a rack.

  • Page 63: Standard Rack Installation

    2 Mount the helper bracket in the lowest available position in the rack using four appropriate screws (not provided), as shown in Figure Figure 26: Helper Bracket for Mounting the BlackDiamond 10808 Switch EX_086A 3 Using all four handles, lift the switch from the pallet, as shown in...
  • Page 64 5 Using the higher handles at the front, slowly guide the chassis into the rack until it is securely seated. 6 While holding the empty chassis, secure the chassis to the rack, using eight rack-mount screws (see Figure 28). EX_090A BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 65 Installing the Chassis Figure 28: Securing the BlackDiamond 10808 Chassis to a Standard Rack EX_009A 7 After you secure the chassis to the rack, remove the helper bracket. Store the bracket for future use; for example, if you need to remove the chassis from the rack.

  • Page 66: Mid-Mount Rack Installation

    (not provided), as shown in Figure 29: Helper Bracket for Mounting the BlackDiamond 10808 Switch 3 Attach a mid-mount flange to each side of the BlackDiamond 10808 chassis using the provided screws. Use the appropriate flange for the left and right side, as shown in...
  • Page 67 Installing the Chassis Figure 30: Mid-mount Flange for the BlackDiamond 10808 Chassis Midmount flanges EX_075 BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 68: Grounding The Chassis

    Store the bracket for future use, for example, if you need to remove the chassis from the rack. Grounding the Chassis Although grounding the BlackDiamond 10808 chassis is optional, it is recommended. A grounding point with integrated pem-nuts is provided on the back of the chassis.

  • Page 69: Initial Management Access

    6 Connect the other end of the wire to a known reliable earth ground point at your site. Initial Management Access After your switch has completed all power on self-tests, it is operational. You can log in and configure an IP address for the default VLAN (named default).
  • Page 70 Installing a BlackDiamond 10808 Chassis BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 71: Chapter 6: Installing Power Supply Units In The Blackdiamond10808 Switch

    WARNING! Extreme Networks AC PSUs do not have switches for turning the unit on and off. Remove the wall plug from the electrical outlet to disconnect the power to an Extreme Networks AC PSU. Make sure that this connection is easily...

  • Page 72: Blackdiamond Psu Compatibility

    WARNING! Extreme Networks DC PSUs do not have switches for turning the unit on and off. Make sure that the DC circuit is de-energized before connecting or disconnecting the DC power cord at the DC power socket on an Extreme Networks DC PSU.

  • Page 73: Required Tools And Equipment

    1 Attach an ESD-preventive wrist strap to your bare wrist and connect the metal end to the ground receptacle on the top left corner of the switch front panel. 2 Verify that the Extreme Networks 700/1200 W AC PSU is right side up and the locking handle is open (see Figure 33).

  • Page 74: Removing Or Replacing An Extreme Networks 700/1200 W Ac Psu

    Installing Power Supply Units in the BlackDiamond10808 Switch CAUTION Do not slam the PSU into the system switch backplane. Use the locking handle to secure the PSU in the power supply bay. Figure 34: Inserting the PSU into the Power Supply Bay 4 Secure the in the power supply bay by pushing down on the locking handle until it clicks in place.

  • Page 75: Leds On The 700/1200 W Ac Psu

    Power Supply Cords Extreme Networks 700/1200 W AC PSUs are shipped with both 110 V AC and 220 V AC power supply cords. The 110 V AC power supply cord allows a maximum DC output power of 700 W. The 220 V AC power supply cord allows a maximum DC output power of 1200 W.

  • Page 76: Installing An Extreme Networks 1200 W Dc Psu

    The wire size must be a minimum of 16 AWG (1.0 mm ● WARNING! Be sure that the source outlet is properly grounded before plugging the AC power cord into the Extreme Networks AC PSU. Installing an Extreme Networks 1200 W DC PSU This section describes how to install the Extreme Networks 1200 W DC UL-listed accessory power supply unit (Model # 60021/PS 2350) in the BlackDiamond 10808 switch.

  • Page 77: Minimum Software Required

    Minimum Software Required The MSM in your BlackDiamond 10808 switch must be running ExtremeXOS version 11.3 or later for the system to recognize the DC PSU. Pre-Installation Requirements You need the following tools and equipment to install or remove a 1200 W DC PSU: ESD preventive wrist strap ●...

  • Page 78: Installing A 1200 W Dc Psu

    CAUTION Be sure that the grounding point on the back of the switch chassis is securely connected to earth ground. For information about grounding the switch, see 2 Verify that the 1200 W DC PSU is right side up, and press the yellow locking lever to the left while...
  • Page 79 An AC power cord is not required for proper functioning of the DC PSU. 6 Rotate the locking handle down to latch the input cable connector onto the DC PSU. BlackDiamond 10808 Switch Hardware Installation Guide Installing an Extreme Networks 1200 W DC PSU EX_131 Figure...
  • Page 80 For example, you should route the leftmost cable harness across the switch so that it exits through the right side of the grate. Route the rightmost cable harness across the switch so that it exits through the left side of the grate. The four middle cables can route in either direction.

  • Page 81: Removing An Extreme Networks 1200 W Dc Psu

    Always be sure that the 1200 W DC PSU does not have the input cabled connected at any time when the DC PSU is not installed in the switch. Do not remove the DC PSU from the switch before disconnecting the input DC cable from the PSU.

  • Page 82: Leds On The 1200 W Dc Psu

    Predictive failure No input power to this PSU only No input power to any PSU Power supply failure Table 10 identifies the symbols and Power Predictive Fail Fail Green Amber Amber Blinking Blinking Blinking BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 83: Chapter 7: Installing Blackdiamond 10808 Modules

    Read the information in this chapter thoroughly before you attempt to install or remove an MSM or I/O module. Module Slot Assignments The specific slot locations for I/O modules and MSMs in a BlackDiamond 10808 switch are as follows: Slots 1, 2, 3, 4, 5, 6, 7, and 8 must have I/O modules.

  • Page 84: Module Slot Assignments

    2 Attach the ESD-preventive wrist strap to your bare wrist and connect the metal end of the wrist strap to the ground receptacle on the top left corner of the switch front panel. 3 Remove the blank faceplate from the slot, if applicable.

  • Page 85: Installing A Blackdiamond 10808 Series Module

    Figure 40: Module Orientation for Insertion in a BlackDiamond 10808 Chassis Module status LEDs Module reset button Management port Console port Compact flash EX_016 7 Slide the module into the slot until it makes contact with the backplane. NOTE Use the metal panel, not the circuit board, to guide the module into place.

  • Page 86: Making Network Interface Cable Connections

    ● Flow control—XON/XOFF ● The terminal or PC with terminal-emulation software that you connect to an Extreme Networks switch must be configured with these settings. This procedure is described in the documentation supplied with the terminal. Appropriate cables are available from your local supplier, or you can make your own. To ensure the electromagnetic compatibility of the unit, use only shielded serial cables.

  • Page 87: Logging In For The First Time

    NOTE For more information about logging in to the switch and configuring switch management access, see the ExtremeXOS 12.1 Concepts Guide. 5 At the password prompt, press [Return].

  • Page 88: Installing A Backup Msm

    Depending on the size and complexity of your network, you should install and configure a backup MSM when network disruption will be minimal. You may need to reboot your switch after you use the synchronize command. Verifying the Module Installation After you install a module, verify that it is working correctly by checking the LEDs on the front panel of the module.

  • Page 89: Removing A Blackdiamond 10808 Series Module

    Removing a BlackDiamond 10808 Series Module All BlackDiamond 10808 series modules are hot-swappable. You do not need to power off the system to remove a module. You need the following tools and equipment to remove a module: ESD-preventive wrist strap (provided) ●...

  • Page 90: Installing A Blank Front Panel

    2 Align the blank front panel over the open slot on the chassis (see Position the blank front panel with the EMI gasket to the right. Figure 41: Blank Front Panels on a BlackDiamond 10808 Chassis Blank front panels 3 Use a #2 Phillips screwdriver to tighten the captive screws at each end of the blank front panel.

  • Page 91: Removing A Blank Front Panel

    4 Install an I/O module or MSM in the open slot as described in Series Module” on page NOTE Leave the ESD-preventive wrist strap permanently connected to the switch, so that the strap is always available when you need to handle ESD-sensitive components. Installing or Removing an External Compact Flash...
  • Page 92 5 Remove the card completely and place it in a safe location. EX_003 show memorycard command to ensure that you will not lose any data when you remove command, you can physically remove the card from the BlackDiamond 10808 Switch Hardware Installation Guide command. eject memorycard...

  • Page 93: Part 3: Installing Blackdiamond Switch Accessories

    Installing BlackDiamond Switch Accessories...

  • Page 95: Chapter 8: Blackdiamond Cable Management

    Interlocking cable holders and cable clips provide additional free-standing, rigid structural support for individual cables and cable bundles in front of the switch. You can use the cable holders and cable clips individually or connect them together to manage multiple cable bundles.
  • Page 96 2 Rotate the cover outward and lift it off the base. Removing the cover exposes the six screws holding the cable guides onto the mounting base (see Figure 44). Cable guides Three screw attachments each side EX_079 BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 97 3 Remove the six screws that secure the cable guides to the mounting base. Save the screws for reattaching the guides later. 4 Set the cable manager mounting base against the rack above the installed BlackDiamond 10808 chassis. Adjust the height of the cable manager base as needed to ensure proper alignment of the screw holes.
  • Page 98 6 Reattach the cable guides to the cable manager mounting base using the screws you removed previously (see Figure Do not overtighten the screws. Figure 46: Securing the Cable Guides to the Mounted Cable Manager Base 46). EX_077 BlackDiamond 10808 Switch Hardware Installation Guide Center screws in first EX_076A...
  • Page 99 Use the cable holders and cable clips to organize and bundle the cables, as described in Cable Holders and Cable Clips” on page Figure 47: Using the Cable Manager BlackDiamond 10808 Switch Hardware Installation Guide Installing the BlackDiamond 10808 Cable Manager 100.

  • Page 100: Using The Cable Holders And Cable Clips

    Latches at top of closed cover Using the Cable Holders and Cable Clips When you use the cable holders and the cable clips, Extreme Networks recommends the following: Attach the cables to the holders by slipping the cable through the opening.

  • Page 101: Connecting Cable Holders

    1 Hold two cable holders as shown in Make sure that one locking tab at the joint is on top and the other is on the bottom. Figure 50: Connecting Cable Holders BlackDiamond 10808 Switch Hardware Installation Guide Using the Cable Holders and Cable Clips Cable...

  • Page 102: Connecting Cable Clips

    1 Hold two clips next to each other with the split sides facing the same way (see Figure 52). 2 Slide the connecting grooves together (see Figure 52). Figure 52: Connecting Cable Clips ENIN001A BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 103 Figure 53: Cable Clip Chain ENIN002A 4 Connect as many cable clips together as you need to manage your cable bundles. 5 To disconnect the cable clips, push on the bottom ring while holding the top ring steady. BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 104 BlackDiamond Cable Management BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 105: Part 4: Blackdiamond Maintenance Procedures

    BlackDiamond Maintenance Procedures...

  • Page 107: Chapter 9: Replacing Blackdiamond 10808 Switch Chassis Components

    ● Replacing a BlackDiamond 10808 Power Supply Controller on page 110 ● NOTE Read the information in this chapter thoroughly before you attempt to install or remove any BlackDiamond 10808 series component. Replacing a BlackDiamond 10808 Switch Fan Tray CAUTION Do not cover or obstruct the fan ventilation holes at the rear of the unit.

  • Page 108: Installing The Replacement Fan Tray

    ESD-sensitive components. Installing the Replacement Fan Tray To install the fan tray in the BlackDiamond 10808 switch: 1 Attach the ESD-preventive wrist strap to your wrist and connect the metal end to the ground receptacle on the top-left corner of the switch front panel.

  • Page 109: Replacing The Blackdiamond 10808 Air Filter

    Replacement filter ● NOTE Extreme Networks recommends that you visually inspect the air filter at least once every three months. Replace or clean as necessary. To replace the filter in the BlackDiamond 10808 switch: 1 Remove the bezel from the front of the chassis using a #2 Phillips screwdriver.

  • Page 110: Replacing A Blackdiamond 10808 Power Supply Controller

    Replacing a BlackDiamond 10808 Power Supply Controller Two power supply controllers installed in the BlackDiamond 10808 switch provide primary/backup redundancy in case one of the controllers fails or is removed. At least one power supply controller must be installed at all times.

  • Page 111: Pre-Installation Requirements

    ● Removing a Power Supply Controller NOTE The power supply controllers are hot-swappable. You do not need to turn off power to a BlackDiamond 10808 switch to remove and replace a power supply controller. CAUTION If you are replacing both power supply controllers, remove and replace the controllers one at a time. After the first controller is removed and replaced, wait for the Status LED to light solid green, indicating normal operation, before you replace the second controller.

  • Page 112: Installing A Power Supply Controller

    Replacing BlackDiamond 10808 Switch Chassis Components Installing a Power Supply Controller NOTE The power supply controllers are hot-swappable. You do not need to turn off power to a BlackDiamond 10808 switch to install a power supply controller. To install a power supply controller: 1 Attach the ESD-preventive wrist strap to your wrist and connect the metal end to the ground receptacle on the top left corner of the BlackDiamond chassis front panel.

  • Page 113: Chapter 10: Repacking A Blackdiamond 10808 Chassis

    CAUTION Before you lift a BlackDiamond 10808 chassis, make sure the chassis is empty to prevent unnecessary weight. This will also prevent damage to the system components due to possible system chassis flex when lifting.

  • Page 114: Required Tools And Equipment

    Repacking a BlackDiamond 10808 Chassis Required Tools and Equipment You need the following tools and equipment to repack a BlackDiamond 10808 chassis: ESD-preventive wrist strap ● Helper bracket that was shipped with the chassis ● Four rack-mount screws appropriate to your organization’s equipment rack ●...
  • Page 115 5 Attach all four restraining bolts to the four shipping brackets to secure the BlackDiamond 10808 chassis to the shipping pallet (see 6 Slide the carton down over the chassis (see Figure 58: Securing the BlackDiamond 10808 Chassis to the Shipping Pallet...
  • Page 116 8 Insert the four v-boards in the corners of the crate (see Figure 61: Inserting the V-Boards V-boards 9 Close the crate flaps and seal them with packing tape. Close lock EX_087C Figure 61). EX_093A BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 117 Figure 62: Nylon Strap Location Pallet CAUTION Do not overtighten the nylon straps. Tighten them securely, but not enough to crush the corners of the shipping crate. BlackDiamond 10808 Switch Hardware Installation Guide Repacking the BlackDiamond 10808 Chassis Figure Corner protectors...
  • Page 118 Repacking a BlackDiamond 10808 Chassis BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 119 Appendixes...

  • Page 121: Appendix A: Safety Information

    Safety Information WARNING! Read the following safety information thoroughly before installing Extreme Networks products. Failure to follow this safety information can lead to personal injury or damage to the equipment. Only trained service personnel should perform service to Extreme Networks switches and their components.

  • Page 122: Maintenance Safety

    WARNING! Extreme Networks DC PSUs do not have switches for turning the unit on and off. Make sure that the DC circuit is de-energized before connecting or disconnecting the DC power cord at the DC power socket on the Extreme Networks DC PSU.

  • Page 123: General Safety Precautions

    Cable Routing for LAN Systems The BlackDiamond 10808 switch meets the requirements for LAN system equipment. LAN systems are designed for intra-building installations; that is, cable runs between devices must be in the same building as the connected units.

  • Page 124: Poe Devices

    IEEE 802.3af. Selecting Power Supply Cords Extreme Networks provides power input cords shipped in the product box for use in the US and Canada. Power supply cords for use outside of the United States and Canada are typically provided separately by third-party distribution centers.

  • Page 125: Battery Replacement And Disposal

    The power cord provided with the power supply, switch, or chassis is for use only with that ● specific product from Extreme Networks; it is not for use with any other product from Extreme Networks or any other vendors' equipment.

  • Page 126: Gbic, Sfp (Mini-Gbic), Xenpak, And Xfp Regulatory Compliance

    Never look at the transmit LED/laser through a magnifying device while it is powered on. ● Never look directly at a fiber port on the switch or at the ends of a fiber cable when they are powered on. ●...

  • Page 127: Hinweise Zur Installation

    Sicherheitshinweise WARNUNG! Vor der Installation der Produkte von Extreme Networks sind die nachfolgenden Sicherheitshinweise aufmerksam zu lesen. Die Nichtbeachtung dieser Sicherheitshinweise kann zu Verletzungen oder Schäden an der Ausrüstung führen. Installation, Wartung und Ausbau eines Switch, einer Grundplatte oder einer seiner Komponenten dürfen nur von geschultem und qualifiziertem Servicepersonal durchgeführt werden! Geschulte und...

  • Page 128: Installation Von Netzteilen

    Safety Information Bei den Extreme-Produkten handelt es sich um digitale Geräte der Klasse A gemäß Teil 15 der FCC- ● Richtlinien und anderen internationalen Richtlinien. Der Gerätebetrieb unterliegt den folgenden Voraussetzungen: (1) Das Gerät kann schädliche Interferenzen verursachen, und (2) das Gerät muss jede empfangene Interferenz zulassen, einschließlich einer Interferenz, die einen unerwünschten...

  • Page 129: Allgemeine Sicherheitsvorkehrungen

    Gleichspannungsquelle in Ihrem Gebäude angeschlossen werden. Extreme Networks 325 W AC Netzteile haben keinen An- Aus Schalter. Die Stromzufuhr zu einem Extreme Networks 325 W AC Netzteil wird durch das Ziehen des Netzkabels unterbrochen. Es ist sicherzustellen das diese Verbindung leicht zugänglich ist.
  • Page 130 Networks entweder nur mit einem 110-VAC-Kabel oder mit einem 110-VAC-Kabel und einem 208/220- VAC-Kabel geliefert. Die von Extreme Networks gelieferten Stromkabel sind nur für den Einsatz in den Vereinigten Staaten und Kanada ausgelegt und zugelassen. Stromkabel für den Einsatz außerhalb der Vereinigten Staaten und Kanada werden normalerweise von einem Drittanbieter geliefert und müssen...
  • Page 131 Das mit dem Netzteil, dem Switch oder der Grundplatte gelieferte Verbindungskabel ist nur ■ für den Einsatz mit dem spezifischen Produkt von Extreme Networks vorgesehen und darf nicht mit anderen Geräten von Extreme Networks oder anderen Anbietern verwendet werden. Nordamerika: Versorgungssteckdose, 15 A, NEMA 5-15 für 110-VAC-Netzteile und NEMA L6-15P ●...
  • Page 132 Einhaltung behördlicher Vorschriften durch GBIC, Mini-GBIC, XENPAK und XFP Laserprodukt der Klasse 1 ● EN60825-1+A2:2001 oder jünger, Europäische Richtlinie für Lasersysteme ● Anwendung der CE-Kennzeichnung gemäß der Richtlinien 89/336/EWG EMV und 73/23/EWG für ● Niederspannungsgeräte BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 133: Appendix B: Technical Specifications

    Fully loaded: 242 lb (110 kg) Power supply 7 lb (3.2 kg) BlackDiamond 10808 MSM 10.7 lb (4.9 kg) BlackDiamond 10808 I/O module 9.25 lb (4.2 kg) Safety Standards North American Safety of ITE UL 60950-1:2003 1st Ed., Listed Device (US) CSA 22.2#60950-1-03 1st Ed.(Canada) Complies with FCC 21CFR 1040.10 (US Laser Safety)
  • Page 134 Technical Specifications Table 13: BlackDiamond 10808 Switch Technical Specifications (Continued) International EMC certifications Country-specific Telecom Standards IEEE 802.3 Media Access Standards Note: These standards are module-specific and may not apply to every module in the series. Environmental Standards Environmental Operating conditions Storage &...

  • Page 135: Power Supplies For The Blackdiamond 10808 Switch

    Table 13: BlackDiamond 10808 Switch Technical Specifications (Continued) Acoustic Sound (BlackDiamond 10808 Switch with AC Power Supplies) Sound power in accordance with Sound power EN 300 753 (10-1997) Declared sound power Sound pressure in accordance Bystander sound pressure with NEBS GR-63 Issue 2...

  • Page 136: Connector Pinouts

    @ 23 A Maximum in-rush current: Not more than 80 A for 5 ms Input circuit protection: 50 A Wire harness provided by Extreme Networks with each power supply. Extreme Part# 4340-00028 Wire type: 8 AWG (10 mm ) listed tray cable, copper-stranded rated @ 90 C...
  • Page 137 9-pin to 9-pin (PC-AT) null-modem serial cable. Figure 64: PC-AT Serial Null-modem Cable Pinouts Switch Cable connector: 9-pin female Screen Shell Ground BlackDiamond 10808 Switch Hardware Installation Guide PC/Terminal Cable connector: 25-pin male/female Screen Ground 25pin PC/Terminal...
  • Page 138 Technical Specifications BlackDiamond 10808 Switch Hardware Installation Guide...

  • Page 139: Index

    MSM-1/MSM-1XL modules, 17 MSMs, 17 power supply controller, 14 rack measurement, 55 serial number, 16 specifications, 133 unpacking, 58 BlackDiamond 10808 Switch Hardware Installation Guide BlackDiamond 8810 switch features, 13 grounding terminals, location, 44 installation, verifying, 112 BlackDiamond modules installing, 83...
  • Page 140 G60X I/O module, 22 grounding BlackDiamond 10808 switch, 68 racks, 44 requirements, 54 wiring closet, 41 grounding terminals, location, 44 heating, chassis-to-chassis, 42 helper bracket BlackDiamond 10808 switch, 63, 66 high-line power, 33 humidity, 42 BlackDiamond 10808 Switch Hardware Installation Guide...
  • Page 141 DC wiring for 1200 W DC power supply, 77 IP settings, configuring, 87 labeling system for cables, 46 LEDs I/O modules, BlackDiamond 10808 switch, 29 MSM, BlackDiamond 10808 switch, 19 ports, BlackDiamond 10808 switch, 29 power supply controller, 110, 111...
  • Page 142 BlackDiamond 10808 switch, 57 tools for installing equipment blank front panel, BlackDiamond 10808 external memory card, 91 fan tray, BlackDiamond 10808 switch, 109 module, BlackDiamond 10808 switch, 83 power supplies, 111 rack mount, 56 tools for removing equipment...
  • Page 143 RF interference, 51 verifying the installation, 112 white shipping indicator, 57 wiring closet airflow requirements, 42 electrostatic discharge, 43 floor coverings, 41 grounding, 41 humidity, 42 rack, securing, 45 temperature, 41 wiring terminals, 44 BlackDiamond 10808 Switch Hardware Installation Guide Index...
  • Page 144 Index BlackDiamond 10808 Switch Hardware Installation Guide...

Table of Contents
