This guide describes how to install the ReachNXT
ExtremeXOS switch to detect and initialize the port extender.
Safety Information
Only trained service personnel should perform service to Extreme Networks switches and their
components. Trained service personnel have read all related installation manuals, have the technical
training and experience necessary to be aware of the hazards to which they are exposed in performing a
task, and are aware of measures to minimize the danger to themselves or other persons.
Before installing a ReachNXT 100-8t port extender into your network:
Read the latest installation and safety information provided in the ReachNXT 100-8t User Guide.
●
See Appendix A of the ReachNXT 100-8t User Guide for additional information regarding regulatory
●
compliance certifications.
NOTE
Die deutsche Version der für dieses Produkt von Extreme Networks relevanten Sicherheitshinweise finden sich im
Abschnitt "Sicherheitshinweise" im
folgenden Webseite zum Download zur Verfügung:
Getting Documentation
You can download the ReachNXT 100-8t User Guide and other Extreme Networks product
documentation from:
http://www.extremenetworks.com/services/documentation.aspx
Requirements
Before you begin, make sure you have the following:
ReachNXT 100-8t ExtremeXOS port extender
●
ExtremeXOS switch to serve as the uplinked switch. The uplinked ExtremeXOS switch must be
●
running ExtremeXOS version 11.2 or higher.
Cable to connect the ReachNXT 100-8t to the uplinked ExtremeXOS switch
●
Depending on your installation, you may also have the following:
Optional SFP module, if one will be used as the connector to the uplinked ExtremeXOS switch
●
Optional magnet mounting kit, if you will mount the ReachNXT 100-8t in a fixed location
●
120480-00 Rev. 01
™
100-8t Quick Start Guide
™
100-8t port extender and configure the uplinked
ReachNXT 100-8t User Guide
http://www.extremenetworks.com/services/hardware-userguide.aspx.
. Dieses Installationshandbuch steht auf der
© 2009 Extreme Networks, Inc. All Rights Reserved
1
Advertisement
Table of Contents
Related Manuals for Extreme Networks ReachNXT 100-8t
Summary of Contents for Extreme Networks ReachNXT 100-8t
-
Page 1: Safety Information
Depending on your installation, you may also have the following: Optional SFP module, if one will be used as the connector to the uplinked ExtremeXOS switch ● Optional magnet mounting kit, if you will mount the ReachNXT 100-8t in a fixed location ● 120480-00 Rev. 01 ™... -
Page 2: Using The Magnet Mounting Kit
You must use the AC power adapter to power the ReachNXT 100-8t when using the SFP uplink. 2 Set the ReachNXT 100-8t in its installed location, such as on a table in a conference room. To use the optional magnet mounting kit to install the ReachNXT 100-8t in a fixed location, follow... - Page 3 On each magnet, twist the mounting tab counter-clockwise two full turns (see a Insert the tab on the magnet into a magnet slot on the ReachNXT 100-8t. and slide the magnet in the direction of the narrow end of the tab.
-
Page 4: Configuring The Extremexos Switch Software
● For more information about configuring PoE, refer to the ExtremeXOS Concepts Guide. 2 Enable LLDP for the port to which the ReachNXT 100-8t will be connected. Use the following command to enable LLDP: enable lldp ports [all | <port_list>] 3 Connect the ReachNXT 100-8t uplink port (port 9 or 9x) to the uplinked ExtremeXOS switch.
