BlackDiamond 12800 Series Switches

Hardware Installation Guide

BlackDiamond 12802 Switch
BlackDiamond 12804 Switch
Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
(888) 257-3000
(408) 579-2800
http://www.extremenetworks.com
Published: August 2008
Part number: 104002-00 Rev. 04
