Extreme Networks
BlackDiamond 10K-Series
Switch Installation Guide
Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
(888) 257-3000
http://www.extremenetworks.com
Published: July 2004
Part number: 104000-00 Rev. 02
