Parts List Continued
NOTE: Part numbers are shown for identification purposes only. Not all parts are available for individual sale.
All parts with a link to the Lippert Store can be purchased.
N O
S
U
Y Z
AA
Callout Part# Description
N 425585 4 Pin Pigtail Harness
305115 Hall Effect Right Rear Sensor Harness
306298 Hall Effect Left Rear Sensor Harness
O
307489 Hall Effect Right Front Sensor Harness
307490 Hall Effect Left Front Sensor Harness
P 426526 Power and Ground Supply Harness
Q 421372 Power and Ground Supply Harness
R 331116 Canbus Data Harness
S 243688 Leveling Sensor Harness 35'
T 329080 Canbus Power Connector Harness
U 423094 Leveling Sensor
V 433632 Blue Controller SE
W 425306 Auto Leveling Control Touch Pad
lci1.com
P
V
AB AC AD
574-537-8900
Ground Control
Leveling OneControl
Touch Panel
Installation and Owner's Manual
(For Aftermarket Applications)
Q
T
W
AE AF
Qty. Callout
1 X
1 Y
1 Z
1 AA
1 AB
1 AC
1 AD
1 AE
1 AF
1 AG
2 AH
1 AI
1 AJ
5
(3K-5K)
R
X
AG AH
Part# Description
406345 OneControl Touch Panel
191021 Hex Washer Head Screw, 3/8" - 16 x 1"
118076 Bolt, 1/2" - 20 x 1 1/2"
663511 Flange Bolt, 3/8" - 16 x 1 1/2"
690759 Wood Screws, #8 x 1"
241940 Self-Drilling Square Head Screws, #8
206614 Hex Cap Screw Bolt, 3/8" - 16 x 3 1/2"
378272 Carriage Bolt, 5/16" - 18 x 1"
119075 Flat Washer, 3/8"
119072 Serrated Flange Nut, 3/8"
117891 Serrated Flange Nut, 5/16"
178210 Serrated Flange Nut, 1/2" - 20
365417 Hex Serrated Flange Nut, 3/8" - 16
CCD-0002700
TT
®
®
AI AJ
Qty.
1
8
12
12
4
4
4
12
4
4
12
12
12
