Configuring the Switch
Once you enter these parameters and reboot the switch, you can log off the local console connection. You can perform
all additional configuration over your Ethernet network using a telnet session.
Only one console connection is allowed at any time. To reach the SmartSwitch
Note
6A000 through telnet, you must exit the local terminal connection by entering the
exit
The following is an example of the initial configuration session. Note that your start up screen may look slightly
different, but the same information is requested.
SmartSwitch 6A000 Version 2.3 (c) Cabletron Inc.
password:: admin
The current user is Administrator
Could not find setup file
Running Setup Automatically
SwitchName() : SmartSwitch
IPAddress(0.0.0.0) : 210.160.77.254
IPNetMask(255.0.0.0) : 255.255.255.0
Default Gateway () : 210.160.77.1
Confirm(y/n)?:y
Changing IP Address on System. Telnet session (if any) will be lost.
SmartSwitch #
3.1.1

Backup Configuration

Backup configuration consists of setting up the SmartSwitch 6A000 to save configuration backup files. The backup
configuration file contains all configuration changes made to the switch. For example, the backup file contains ELAN
information, port configuration changes, PVCs, filters, and so on.
Note The backup file does not contain an image of the switch operating firmware. For
information on upgrading or replacing switch firmware, see the SmartSwitch
ATM User Guide.
Perform the following steps to configure backup capabilities.
On a workstation that can be reached by your SmartSwitch 6A000 and is running TFTP server
1.
software, create a file under the /tftpboot directory. This file is used as the backup file by the
SmartSwitch 6A000, and can initially be blank.
Make sure that the SmartSwitch 6A000 has full read/write privileges to the file.
2.
3. Enter the
backup switch
server and the full path and file name to the backup file. For example:
SmartSwitch # backup switch
ServerIP()
Path(public/Smart6A000.ztr)
SmartSwitch #
command.
— "admin" is the default password
— a switch name
— an IP address
— a subnet mask
— address of the default gateway
command on the SmartSwitch 6A000. Specify the IP address of the TFTP
: 206.61.237.40
: /tftpboot/backup.ztr
— IP address of the backup TFTP server
— full path and file name
SmartSwitch 6A000 Installation and Setup Guide 3-3
Switch Configuration
