ATM Administrator
Add routes on Switches 4 and 5 that specify the LANE client of their adjacent switches as the
2.
gateway to the Ethernet network (126.231.44.0 in this example).
All switches specified as gateways must have connectivity to both the Ethernet
Note
and ATM networks.
For instance, in Figure 4-8, after the route is added to the NMS, a route must be added to Switch 4 that specifies Switch
1's LANE client as the gateway to the Ethernet network. To add the route on Switch 4, use the
command:
SmartSwitch # add route
DestNetIP()
GatewayIP()
SmartSwitch #
Similarly, a route must be added to Switch 5 that specifies Switch 2's LANE client as the gateway to the Ethernet
network:
SmartSwitch # add route
DestNetIP()
GatewayIP()
SmartSwitch #
To see the new route, enter the
SmartSwitch # show route
ROUTE NET TABLE
destination gateway
------------------------------------------------------------------------
90.0.0.0 90.1.1.20
206.61.237.0 90.1.1.22
------------------------------------------------------------------------
ROUTE HOST TABLE
destination gateway
------------------------------------------------------------------------
127.0.0.1 127.0.0.1
------------------------------------------------------------------------
SmartSwitch #
: 206.61.237.0
: 90.1.1.22
: 206.61.237.0
: 90.1.1.15 — Switch 2's LANE client
command. As an example, we do this on Switch 4:
show route
flags Refcnt
1 0
3 0 0
flags Refcnt
5 0
— Switch 1's LANE client
Use Interface
0 zn5
— Switch 4's new route to Ethernet network
zn5
Use Interface
0 lo0
SmartSwitch 6A000 Installation and Setup Guide 4-9
Managing Your ATM Network
console
add route
