Switch Installation
Table 2-1
Face Plate Number
IOM-29-4-LR
IOM-31-1
IOM-39-1
IOM-39-1-LR
IOM-67-4
IOM-77-4
All Single-Mode fiber connectors on IOMs are blue.
Note
If the switch hardware configuration is incorrect, contact Cabletron Global Support Center immediately.
2.3

INSTALLING THE SWITCH

The SmartSwitch 6A000 is hot swappable, meaning that you can install and remove it without turning off or
unplugging the SmartSwitch 6000 chassis. You can install as many as five switch modules in each chassis (using the
6C205-3 power supply). In this configuration, the SmartSwitch 6A000 modules provide up to 75 user ports. Modules
should be connected with inter-module trunks if traffic must cross between modules. Table 2-2 shows the maximum
number of LAN and ATM switch modules that can be installed in a SmartSwitch 6000 chassis.
Table 2-2
Number of 6Exxx or 6Hxxx modules installed
Number of 6A000 modules that can be added
Note A single 6C205-1 power supply (the older version of the 6C205-3) can support
only two SmartSwitch 6A000s within a SmartSwitch 6000 chassis. Three
SmartSwitch 6A000s can reside within a SmartSwitch 6000 chassis that contains
two 6C205-1 power supplies.
Follow the instructions below to install the switch module into the chassis. Refer to Figure 2-2.
I/O module ID numbers (Continued)
Physical Specification
155 Mbps OC-3/STS-1, SMF-LR/SC (4 port)
622 Mbps OC-12/STM-4, MMF/SC (1 port)
622 Mbps OC-12/STM-4, SMF-IR/SC (1 port)
622 Mbps OC-12/STM-4, SMF-LR/SC (1 port)
45 Mbps DS-3, Coax/BNC (4 port)
34 Mbps E-3, Coax/BNC (4 port)
SmartSwitch 6000 contents
0
5
1 2 3
4 3 2
SmartSwitch 6A000 Installation and Setup Guide 2-3
Installing the Switch
4 5
1 0
