Specifications
Table 5-3
Specification
Dimensions
Product weight (with max I/O modules)
Power requirements (typical)
Power dissipation (typical)
Operating temperature
Operating humidity
Table 5-4
Media Port Speed Framing
SMF-IR 155 Mbps STS-3c or STM-1
SMF-IR 622 Mbps STS-12c or STM-4 SC
SMF-LR 155 Mbps STS-3c or STM-1
SMF-IR 622 Mbps STS-12c or STM-4 SC
MMF 155 Mbps STS-3 or STM-1
MMF 622 Mbps STS-12c or STM-4 SC
Cat. 5 155 Mbps STS-3c or STM-1
UTP
75 ohm 44.7 Mbps DS-3
coax nonchannelized
75 ohm 34.3 Mbps E-3 nonchannelized BNC,
coax
Physical Specifications
Value
41.9 cm x 6.1 cm x 28.6 cm
16.5" x 2.4" x 11.25"
3.6 kg
8 lbs
5V, 19 amps at chassis power bus (fully
loaded)
1,008,000 BTU/s (95 watts) (fully loaded)
15 to 40 C (41 to 104 F)
5% to 90% RH, non-condensing
ATM Port Specifications
Connector
SC
SC
SC
RJ-45
BNC,
female
female
Max. Rx
Max. Tx Min. Tx
power
Power power
-8 dBm -15 dBm -8 dBm
-8 dBm -15 dBm -7 dBm
0 dBm -5 dBm -8 dBm
+2 dBm -3 dBm -7 dBm
-14 dBm -19 dBm -14 dBm
-14 dBm -20 dBm -14 dBm
-- -- --
n/a n/a n/a
n/a n/a n/a
SmartSwitch 6A000 Installation and Setup Guide 5-3
Technical Specifications
Min. Rx Range
power
-31 dBm 15 Km
-28 dBm 15 Km
-34 dBm 40 Km
-28 dBm 40 Km
-31 dBm 2 Km
-26 dBm 500 m
-- 100 m
n/a 150 m to
DSX
n/a 150 m to
DSX
