SPLITMUX Quad Screen 4K Multiviewer

Telnet Control

To control the SPLITMUX using telnet from the command line, the SPLITMUX must first be connected to the Ethernet.
Note: Telnet must be enabled through the web interface (page 20) for a connection via Telnet to be possible.
To open a telnet session to the SPLITMUX, Issue the following command from the command line:
telnet <SPLITMUX IP address> 2000
<SPLITMUX IP address> is IP address of the SPLITMUX (default is
The user will be prompted for the root password to connect to the SPLITMUX.
The factory default password is "nti".
With a proper password sent the SPLITMUX will respond with:
Password Successful
Connection Established
The commands below are now available.
Command String Good Response
CS,ip,01
CM,mode,01
CF Login Prompt
CB 00,BR
LA,nn
RU *<CR>IP,OP<CR>
RS
(all lowercase letters).
*<CR>
*<CR>
None
BR=11(5200),57(600),38(400),19(200)96(00),48(00),24(00),12(00)
*<CR>
*<CR>
Note: When making a Telnet
connection through any terminal
software, be sure to configure to
192.168.1.30
).
connect through port 2000.
Description
Connect input X to the output port
Change the mode of the switch
Open Text Menu
Change baud rate of serial line,
Factory default is 9600
Load saved custom layout (01-10)
Read Unit Size
Reset unit
