SPLITMUX Quad Screen 4K Multiviewer

COMMAND LINE INTERFACE

The SPLITMUX can be controlled using a command line interface from either a terminal connection to the "RS232" serial port
(page 10) or through an Ethernet connection (page 10).

RS232 Control

The RS232 Interface is designed to meet the RS232C standard and can be controlled from any CPU or other controller with an
RS232 communications port. The pin-out for the RJ45 connector on the unit is as follows:
RS232 (RJ45) CONNECTOR
PIN SIGNAL FUNCTION
1 - No connection
2 - No connection
3 RX+ Receive data (TXD at host)
4 GND Ground
5 - No connection
6 TX+ Transmit data (RXD at host)
7 - No connection
8 - No connection
A 5 foot patch cable and adapter, RJ45-to-DB9, have been provided for connection to most CPUs (see page 10).

Baud Rate

The baud rate can be changed using the OSD menu (page 56), using Telnet commands (page 38) from the RS232 commands
(page 37), from the Text Menu (page 42), or through the WEB Interface (page 18). The baud rate can be set to 115200, 57600,
38400, 19200, 9600, 4800, 2400, or 1200. A data protocol of 8 data bits, no parity, and 1 stop bit is used for communications.
The default baud rate setting is 9600. The terminal should be in VT100 terminal mode.
