Speaker Config

5.1 – 6.1 and 7.1 content is mapped to a 5.1 speaker configuration and 5.1 content is
unmodified.
7.1 –5.1 and 6.1 content is mapped to a 7.1 speaker configuration and 7.1 content is
unmodified.
Phantom Center
Off – Normal operation with a center channel speaker.
On – Use when center channel speaker is not available. The information from the center
channel plays on the left and right channels. Note: This is only in effect while playing
audio through the decoder.
DTS Neo:6 Option
Off
Music –
center and surround channels from the 2-channel
Cinema – Neo:6 Cinema creates 6.1-channels, from 2-channel movie sources. It
removes in-phase information from the Left/Right signals and uses it to create the
center channel. Out-of-phase information is extracted and sent to the surround
channels.
Note: DTS Neo:6 is applied only when receiving 2-channel stream.

Misc Options

Direct Mode –
Disable Surround Remap – When enabled, this option will not remap the playback of
5.1 content to 7.1 speaker configuration.
DTS LFE +10dB – Removes the +10dB LFE boost applied to the LFE channels when
playing DTS decoded audio. This option may be required for older DTS audio discs.
4.3.7 EQ Setup
Menu (System) > Formats > Audio EQ Setup
Figure 54. Audio EQ Setup Screen
AP25 Installation & Operating Guide
AP25 Installation and Operating Guide
Neo:6 Music keeps the front left and right channels intact while synthesizing the
Processing is disabled.
source.
