Datasat AP25 Installation And Operating Manual page 66

Figure 41. Home Screen Format Button Locations
4.3.4.1 Enable "More" Button
Selecting the Enable "More" Button from the Format Button Assignment screen allows access
to more than the eight format buttons normally available on the Home screen. When the Enable
"More" Button is not selected, the Home screen will display up to eight assignable format
buttons on the bottom of the screen. When the Enable "More" Button is selected, format
buttons 1-7 will be displayed and button 8 will display <More> (see Figure 41). Selecting the
<More> button on the Home screen brings up a pop-up window which allows you to select from
all formats.
Figure 42. Home Screen <More> Format Select
AP25 Installation & Operating Guide
AP25 Installation and Operating Guide
Button location 5 Button location 8
Document # 9301H79500 Ver. 1.00
Page 66
