Digital Out ClockRate – When interfacing with external digital equipment select appropriate
clock rate to match that equipment. Select from the following options:
Off
48 kHz
96 kHz
192 kHz
Output Mapping – Channels 9-16:
Ch 9-16 Out Normal – Standard output channel assignments.
Copy Ch 1-8 to Ch 9-16 – The output of channels 1 through 8 will be copied to output
channels 9 through 16 for both the Analog output connector and Digital output
connector. Output channels 9-16 are not assignable if this option is used.
Output Mapping – Channels 17-24 (Only available when optional H539 board is installed):
Ch 17-24 Out Normal – Standard output channel assignments.
Copy Ch 1-8 to Ch 17-24 – The output of channels 1 through 8 will be copied to output
channels 17 through 24 for both the Analog output connector and Digital output
connector. Output channels 17-24 are not assignable if this option is used.
Copy Ch 9-16 to Ch 17-24 – The output of channels 9 through 16 will be copied to output
channels 17 through 24 for both the Analog output connector and Digital output connector.
Output channels 17-24 are not assignable if this option is used.
Fader Control – The Fader knob controls the playback level in the auditorium/theater. It can be
set in either of two modes:
Global: The fader level setting will affect all audio formats and will not be displayed in
the Home screen. Example: While in a format and the fader is adjusted from 5.0 to 6.0,
the fader will remain at 6.0 when another format is selected.
Format: Fader level settings can be assigned to each audio format button on an
individual basis. To differentiate it from the Global setting and allow an easy reference
for the projectionist, the fader level setting for the format will display at the top of the
Home screen below the text "Fmt Fader". In this mode, if a fader level is adjusted for a
specific format, it will not affect other formats. See next topic.
Note: This setting will not affect the main fader display on the Home screen.
Note: If the operator needs to preset the level for each audio format, then set up Fader Control
to be in Format mode.
