Page 6 Page 6 Introduction This manual explains the AP20 Audio Processor setup and operation. It contains full instructions for installing hardware and software, setting up audio playback, configuring the system, performing maintenance and troubleshooting, and setting up and operating optional functions.
Page 7: Limited Warranty
All internal control and data lines are available to expansion cards to service future user needs. To get the most out of your AP20, we suggest that you review this manual and keep it available during system installation and initial operation.
Page 8 We publish the Tech Talk newsletter with tips and updates for Service Technicians. Tech Talk is published quarterly, and e-mailed. If you would like to be added to our mailing list, contact Datasat Digital Entertainment Technical Support. It is also posted on the free online Support Center located on our website at www.datasatdigital.com.
Page 9: Contact Information
Entertainment hereby grants you a non-exclusive, non-transferable, revocable, limited license to use the Software solely for your internal business purposes and solely in connection with the AP20 Audio processor. All rights not expressly granted to you are reserved by Datasat Digital Entertainment.
Page 10 INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, LOSS OF DATA, BUSINESS INTERRUPTION OR ANY OTHER COMMERCIAL DAMAGES OR LOSSES, ARISING OUT OF OR RELATED TO YOUR USE OF THE DATASAT DIGITAL ENTERTAINMENT SOFTWARE OR HARDWARE, HOWEVER CAUSED, REGARDLESS OF THE THEORY OF LIABILITY AND EVEN IF DATASAT DIGITAL ENTERTAINMENT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Page 11: Important Safety Instructions
The packaging is designed to handle normal shipping and handling. Upon receipt of shipment, check for signs of damage before opening and report all damage to the carrier. All shipments made from Datasat Digital Entertainment are customer responsibility once they leave our premises.
Page 12 Caution Notices Power Cord to the AP20 rear panel: The power cord is the main disconnect device. It should be plugged into an easily accessible outlet with surge protection. The power cord is to be used in a minimum type SVT 18/3 rated 250 Volts AC, 10 Amps with a maximum length of 4.5 M, with one end terminated in an IEC 320 attachment plug and the other end...
Page 13: Table Of Contents
AP20 Installation and Operating Guide Page 13 Part 1: Operation This part of this manual contains information the user needs to operate the AP20 Audio Processor on a day-to-day basis. OPERATING AP20 – O ROCEDURES PERATIONS RONT ANEL ONTROLS AND...
Page 14: Operating Ap20
Turn clockwise to increase volume. See Adjusting the Fader, page 18. Select a format Touch the desired format in the bottom row of the AP20 display. If the format you want is not shown, then that format is not available. See The Home Screen, page 18.
Page 15: Front Panel Controls And Indicators
USB port Power button Figure 1: Front Panel Controls and Indicators The front panel contains the following controls and indicators for operating AP20. Power button: Turns the unit on and off LCD/Touch Screen: Displays theater system configuration and status and allows configuration changes.
Page 16: Powering On The Ap20 Processor
15 seconds to initialize. A “soft boot” (pressing the power button on the front panel when power has not been cycled) typically takes about 20 seconds. While the system is initializing, the following messages will appear on the AP20 touch screen. Figure 2. Initial screen Figure 3.
Page 17: Navigating Through The Menus
Navigating through the Menus Since the AP20 is equipped with a touch screen display, you can navigate easily through the menus by touching any button with your finger. A non-abrasive stylus that will not scratch the screen can also be used if you prefer.
Page 18: The Home Screen
The button label and fader display will turn red. The button label will also change to “Muted”. Unmute the AP20 by touching the mute button again, or changing formats. If in the Home Screen, increasing the fader volume using the control knob will also unmute.
Page 19: Booth Monitor Volume
Figure 7. Fader Muted 1.4.2 Booth Monitor Volume When an external powered speaker is connected to the AP20, the level can be controlled using the monitor volume. To adjust the booth monitor volume, touch the Monitor button. The screen shown in Figure 8 will appear.
Page 20: Manual Automation
AP20 Installation and Operating Guide Page 20 Touch the small button to select a channel for monitoring Figure 9. Monitor Mix Select channel(s), then touch the + or – button to adjust volume from 0 to 10. Touch the small button next to a channel to select it for monitoring.
Page 21: Troubleshooting (Operation )
Use touch screen work around until fader can be repaired (see section 5.2) and contact your theater technician. 1.5.1 Over Temperature Alert If the internal temperature of the AP20 reaches a critical level of 50°C or greater, a red flashing alert indicator will appear. AP20 Installation & Operating Guide...
Page 22 AP20 chassis. Check that there is nothing obstructing these air vents. Be sure that the fan is spinning (you will feel air blowing out of the AP20 from the fan). If the vents are clear and the fan is spinning, yet the temperature alert does not stop, call Datasat Technical Service or your technician.
Page 23 AP20 Installation and Operating Guide Page 23 Part 2: Installation and Setup This part of this manual contains information the theater technician needs to set up and configure the AP20 Audio Processor. PART 2: INSTALLATION AND SETUP INSTALLATION AND SET UP...
Page 24: Ap20 Installation And Operating Guide
AP20 Installation and Operating Guide Page 24 4.2.2 AP20 S PDATING OFTWARE 4.2.3 AVING AND ESTORING ONFIGURATION ILES 4.2.4 CCESS ONTROL 4.2.5 4.2.6 YSTEM 4.2.7 ERSION ERIAL UMBER ADDRESS 4.2.8 YSTEM ONITOR ORMATS 4.3.1 URRENT UDIO ORMAT 4.3.2 TARTUP ORMAT 4.3.3...
Page 25: Installation And Set Up
AP20 Installation and Operating Guide Page 25 Installation and Set Up 2.1 Installation Checklist This checklist summarizes the installation and setup procedures for the AP20. Table 2: AP20 Installation and Setup Completed Task Description Refer to: Install AP20 in Equipment Rack...
Page 26 2.4 AP20 Rear Panel Connections Figure 12 shows the rear panel of the AP20. Table 3 gives a description of each connector shown in the figure. For specific information on the pin-outs of each connector, please see Appendix A of this manual.
Page 27 AP20 Installation and Operating Guide Page 27 14 15 16 17 Figure 12. AP20 Rear Panel Table 3. AP20 Rear Panel Connections ITEM DESCRIPTION ITEM DESCRIPTION Power Entry Module/Power Switch Digital Audio In (CH 9 – 16) – DB25F Option Card Slots (3) example: Optical Film Digital Audio Out (CH 1 –...
Page 28 When using the Digital Out, make sure the input device is set to the same sample frequency as the AP20 and that it’s clock source is set to input. Sample rate choices are 48kHz, 96kHz, and 192kHz. Select the highest rate supported.
Page 29 (usually to scroll through a list or to increase/decrease values): Note: When using a laptop to VNC into the AP20, use the up and down arrows to mimic the scrolling action of the front panel adjustment knob.
Page 30 AP20 Installation and Operating Guide Page 30 Figure 13. Global Settings and Format Discrete Settings AP20 Installation & Operating Guide Document # 9301H39200 Ver. 1.25...
Page 31 AP20 Installation and Operating Guide Page 31 In the Audio Format Setup screen, five options appear along the bottom: Input Source, Format Options, Audio EQ Setup, Channel Profile, and Audio Levels. Menu (System) > Formats Figure 14. Audio Format Setup Screen 2.7.1 Creating an Audio Format...
Page 32: Factory Presets
Third Octave EQ: Calibrated adjustment made by qualified technician Parametric Equalization: Calibrated adjustment made by qualified technician 2.8 Factory Presets The AP20 factory settings include formats for Digital Cinema and Nonsync as described in the table below. Table 4. AP20 Factory Presets...
Page 33 AP20 Installation and Operating Guide Page 33 Table 5. AP20 Preset Formats Name Source Digital Cinema Digital In (1-16) HDMI 1 HDMI Port 1 HDMI 2 HDMI Port 2 HDMI 3 HDMI Port 3 HDMI 4 HDMI Port 4 Nonsync1...
Page 34 EQ. The laptop computer must be connected to the Ethernet port of the AP20 in order to take advantage of the remote operation feature. You can use a wireless router (not supplied by Datasat) such as the Linksys WRT54GL or a router with a network cable for this connection.
Page 35 The laptop computer uses a Virtual Network Connection (VNC) to communicate with the AP20. The front panel touch-screen display of the AP20 will appear on the laptop screen, but will not function as a touch-screen. Use the laptop’s cursor and arrow keys to make selections.
Page 36 AP20 Installation and Operating Guide Page 36 Figure 15. Channel Names Screen When channel assignments are complete, you can eliminate the unassigned channels so they do not appear on the main screen. Turn off the Vu indicator for unused channels.
Page 37 2.9.6 Verify Channel Assignments in Auditorium On the AP20, select a channel and turn on Pink Noise. In the auditorium, verify that the Pink Noise output is coming from the correct loudspeaker(s). Do this for all channels. For details, see Audio Levels, page 94.
Page 38 AP20 Installation and Operating Guide Page 38 Caution: Before proceeding with the room equalization, it is imperative that the loudspeaker and crossover systems be properly aligned. Issues like speaker phasing and horn tilt need to be checked. When using crossovers the low, mid and high frequency drivers must be balanced to produce a relatively even response from 100 Hz to 5 Hz.
Page 39 * Subwoofer should be set to 10 dB of in-band gain (see SMPTE RP-200), which equates to approximately 91 dBC (slow). If not possible to achieve the baseline, use the AP20 (Analog Output Levels) to make minor adjustments. AP20 Installation & Operating Guide...
Page 40 If using Dirac Live, please refer to the Dirac Live Theater Setup manual. For an overview, see Using Dirac Live® to Tune the Auditorium, page 44. The AP20 contains a full suite of 1/3 Octave EQ filters that are “traditional” cinema processor filters. If using AP20 1/3 Octave EQ, complete the following steps.
Page 41 AP20 Installation and Operating Guide Page 41 5. Turn on XCurve Display. Try to tune the frequency pattern to the XCurve. If the pattern does not conform – there is a hole or a peak or other variance – then select the frequency that needs adjusting, and push it down or pull it up.
Page 42 2.11 Subwoofer EQ – Parametric EQ The AP20 features Parametric EQ on every channel. Parametric EQ is an optional adjustment and is in addition to 1/3 Octave EQ. It is only available with low frequencies and offers more control than 1/3 Octave EQ.
Page 43 AP20 Installation and Operating Guide Page 43 Figure 21. Parametric EQ Screen, Filter Enabled 2.12 Copy EQ Set to Another EQ Set This screen is used to copy the EQ settings for all channels to a new EQ set under a new name. After equalizing all the channels, copy these settings to create another EQ (with a new name).
Page 44 To do this, save the setup configuration on a memory stick (USB Flash drive), then use the saved setup to copy to the AP20 for the next screen, since many or all the values will be the same. Menu (System) > USB Save/Restore > Save on USB > Master Configuration See Saving and Restoring Configuration Files, page 58 for more details.
Page 45 For digital cinema format, see HDMI Options, page 77 View AP20 System information See 4.2.6 System Info, page 63. Update AP20 software See 4.2.2 Updating Your AP20 Software, page 56. AP20 Installation & Operating Guide Document # 9301H39200 Ver. 1.25...
Page 46 AP20 Installation and Operating Guide Page 46 3.1 Example: Creating a Format Prior to creating a format, it is necessary to identify the following: Input source Format option EQ set up Output channel profile name The following example describes how to create “non-sync 2” format, with stereo input, global delay of 0 ms, assignment of EQ and audio profile.
Page 47: Setup Menus
Setup Menus On the next five pages, you will find a menu diagram for the AP20. This chapter contains a detailed description of all the screens under the "Menu" selection of the home page. Refer to section 1.4 for all operations under the "Home"...
Page 48: System Setup
“System” button will return you to the “System Setup” screen Selecting “Home” from a sub-menu will return to the home screen If “Menu” is then selected, the AP20 will return to the last selected sub-menu The “Back”...
Page 49 AP20 Installation and Operating Guide Page 49 AP20 Menu Structure Home (Main) Software V1.04.00 and above (Page 2) Menu (System) Current Audio Format (select) Copy Format Copy Preset to Format Formats Edit Formats Rename Format Delete Format Mic Power on/off (select)
Page 50 AP20 Installation and Operating Guide Page 50 AP20 Menu Structure Home (Main) Software V1.04 00 and above (Page 3) Menu (System) Formats Format Options Channel Profile Global Delay and Surround Offset (set) Global audio delay for current format (ms) Channel Profile Setup...
Page 51 AP20 Installation and Operating Guide Page 51 AP20 Menu Structure Software V1.04.00 and above (Page 4) Film Setup Azimuth Mute Digital Soundtrack Proj 1/2 (select) Input Graph image Mute Select Input for Digital Optical Gain Mute Soundtrack: None Digital Chs. 1-8 Analog Chs.
Page 52 AP20 Installation and Operating Guide Page 52 AP20 Menu Structure Home Software V1.04.00 and above (Page 5) Setup (System) Automation Network Net Diag: Ping Test (Select Destination) Network Configuration: Log Net Stats DHCP/Sta ic (select) Phy Interface info Automation Events...
Page 53 Selecting the button, after first powering up the AP20, will display the System Setup screen. This will provide access to the Setup menus. In the next section, we will discuss in detail the options available through the menu bar. Pressing the Home button will take you back to the Home or Main screen.
Page 54 AP20 Installation and Operating Guide Page 54 LCD Brightness -Use the on-screen slider or the adjustment knob to adjust the brightness of your LCD screen. Using the buttons along the bottom of the System Setup screen, you can update the processor...
Page 55 AP20 Installation and Operating Guide Page 55 4.2.1 Assign Fader Level to a Format To assign a specific fader level to a format button, do the following: 1. Select Menu (System), then in the Fader Control pulldown menu select format. Return to the main screen by selecting Home button.
Page 56: Updating Your Ap20 Software
4.2.2 Updating Your AP20 Software There are two ways you can update your software. The first way, is to connect to the servers at Datasat Digital Entertainment to select and install the update. This requires that the AP20 be connected to the Internet.
Page 57 The current version of software loaded on the AP20 is displayed under Current on the right side of the screen. The highlighted software version, will display under Selected on the right side of the screen.
Page 58: Saving And Restoring Configuration Files
AP20 will not recognize it. 3. Insert the USB drive into the USB slot on the front panel of the AP20, choose Select Update Source > USB (see Figure 28), select the update file and press the Start Update button.
Page 59 Save Master Config Save AP20 configuration to USB device as MASTER configuration, which may be loaded onto other AP20 units. This will erase from the USB device any existing MASTER configuration. Save Diagnostic Info Save AP20 Diagnostic information to the USB device to facilitate troubleshooting.
Page 60: Access Control
Note: When removing password protection, if no hyphen is entered (blank selection), the AP20 will continue to ask for a password to enter the setup menus. In that case select the OK button to enter the setup menus without entering a password.
Page 61 Figure 32. Net Command Virtual Keyboard 4.2.4.2 “Expert” Nav Mode When “Expert” Navigation Mode is enabled, the normal AP20 menu structure is replaced with a setup screen that provides quick access to the main menu buttons. After enabling, the new screen appears when the “System”...
Page 62: View Log File
The Screen, Theater, and Circuit information may be used by a remote theater management system or other custom application software. 4.2.4.5 Feature Key This is for future use and not currently used for AP20. This will be used to enter an unlock code when upgrading to optional features. 4.2.5 View Log File The log file (shown in Figure 34, below) is a complete listing of all software events that have taken place since the AP20 was last powered on.
Page 63: System Info
AP20 Installation and Operating Guide Page 63 4.2.6 System Info From the system Setup screen, touch the System Info button. The System Info screen is shown below. Menu (System) > System Info Tap touch screen to see more information such...
Page 64: Formats
AP20 Installation and Operating Guide Page 64 The blue portion on the first screen displays board information such as board ID, Address, hardware revision level, loader version, loader check-sum, firmware version, and firmware check-sum. The blue portion on the second screen displays the expected and actual bus voltages for each board.
Page 65: Startup Format
Page 65 4.3.2 Startup Format The Startup format is the default format selection when the AP20 is powered up. Select any defined format or Last Format. Touch the drop down list to open it, then select the format. Figure 38. Select Startup Audio Format 4.3.3 Edit Formats...
Page 66: Assign Format Buttons
AP20 Installation and Operating Guide Page 66 Rename Format – Give an existing audio format a new name. Select an existing format from the drop-down list on the right side of the screen. Touch the “To” box to bring up the virtual keyboard and enter a new name for the format.
Page 67 AP20 Installation and Operating Guide Page 67 Button location 1 Button location 8 Figure 41. Home Screen Format Button Locations 4.3.4.1 Enable “More” Button When the Enable “More” Button is not selected, the Home screen will display the eight assignable format buttons on the bottom of the screen (see Figure 41). When the Enable “More”...
Page 68: Input Source
Decoder appears for input selections Digital 1,2; Digital 9,10; TosLink A & B; S/PDIF; and HDMI 1-4. See Table 12 (below) for a description of where input channels will be routed within the AP20. Figure 43. Input Source Screen AP20 Installation & Operating Guide...
Page 69 If a Dolby Digital bitstream is detected and decoded, the decoded stream will be routed to the first eight channels internally on the AP20. See section 4.3.6.6 Decoder Setup for more information. AP20 Installation & Operating Guide Document # 9301H39200 Ver. 1.25...
Page 70: Format Options
AP20 Installation and Operating Guide Page 70 4.3.6 Format Options The Format Options screen allows changes to Global Delay, Extended Surround Options, Nonsync Levels and Routing, Mic Level and Routing, Matrix and Routing, Digital Cinema Format Options, Decoder Setup and Film Options (if the optional Optical Film card (H338) is installed – see appendix F).
Page 71 Subtract surround distance from the screen distance, and add 20 (screen - surround + 20). The result is the surround delay in milliseconds. After setting the surround delay in the AP20, verify the setting by listening to a familiar soundtrack. The action on-screen should match sound in the auditorium.
Page 72 AP20 Installation and Operating Guide Page 72 4.3.6.2 Extended Surround Options This screen is available for input source Analog 8ch. Menu (System) > Formats > Format Options > Extended Surround Options Figure 46. Extended Surround Options None – No surround option, signals are not re-routed.
Page 73 AP20 Installation and Operating Guide Page 73 4.3.6.3 NonSync Level and Routing This screen is available for Nonsync 1 or 2 input sources only. Menu (System) > Formats > Format Options > NonSync Level and Routing Figure 48. Nonsync Level & Routing Adjust the input levels of Nonsync1 and Nonsync2 by selecting the box under L or R and turning the fader knob.
Page 74 RTA. Select an optical format on the AP20, enable pink noise on the center channel, and note the level and low frequency roll off displayed on the RTA. Select the appropriate Low Pass Filter setting by pressing that button and using the fader knob to make any changes required to match the low pass filter to the roll off measured.
Page 75 AP20 Installation and Operating Guide Page 75 4.3.6.3.2. Nonsync Mic Level and Routing System > Formats > Format Options > Nonsync Level and Routing > Mic Figure 50. Mic Level with Nonsync If Enable Mic is selected in the Nonsync level and routing screen, you can adjust mic level and routing by going to Mic Level and Routing screen.
Page 76 5.1 DCP – Digital In mapping is straight through to the AP20 channels Out. DCP includes HI – Select to route DCP HI In on pin 7 to the AP20 RCA jack. If disabled, HI Out is mixed from DCP In L, R, C..
Page 77 Matrix – Select to expand 2-channel mix to 5 channels or 5.1. Digital In channels 1 (L) and 2 (R) are sent through a matrix and output to AP20 channels Out 1-6 (L, R, C, Lfe, LS, RS) and HI Out is mixed from DCP In L, R, C. The undefined channels 9-16 are mapped directly to the AP20 channels 9-16..
Page 78 AP20 Installation and Operating Guide Page 78 Table 13: Decoder Channel Assignments CHANNEL NUMBER CHANNEL NAME Left Right Center Left Surround Right Surround Back Surround (only with 6.1 playback) Decoder Setup Options Additional Decoder options are available to set the speaker configuration and phantom center option.
Page 79: Eq Setup
AP20 Installation and Operating Guide Page 79 On – Use when center channel speaker is not available. The information from the center channel plays on the left and right channels. Note: This is only in effect while playing audio through the decoder.
Page 80 Press the Delete button to complete the process, or press Cancel to quit. 4.3.7.3 Dirac Optimization The Dirac Live setup procedure must be used to copy Dirac configuration setup files to the AP20 before this screen becomes functional. Ignore this screen if you are not using Dirac Live software to setup the AP20.
Page 81 AP20 Installation and Operating Guide Page 81 Menu (System) > Formats > Audio EQ Setup > Dirac Optimization Figure 56. Dirac Optimization Screen Dirac Room Optimization Enabled/Disabled – Touching the button will toggle between enabling and disabling the Dirac Optimization.
Page 82 AP20 Installation and Operating Guide Page 82 Current format Corner Frequency and EQ Adjust Current audio level and 0dB reference Figure 57. 1/3 Octave EQ Screen Channel Number Selection – Touch the Chan button to bring up a display of all sixteen channels.
Page 83 If Mic Power is ON, it remains ON when you leave this screen and go to other screens. However, Mic Power is automatically disabled when the AP20 resets. This Mic Power setting is independent of the Mic power that is part of Format.
Page 84 AP20 Installation and Operating Guide Page 84 Corner Frequency adjustments – Touch the corner frequency box for treble or bass and adjust using the adjustment knob. The corner frequency for bass can be set from 50Hz to 300Hz. The corner frequency for the treble can be set from 1.5kHz to 12kHz. The corner frequency cannot be set for individual channels—the setting affects all channels in the...
Page 85 AP20 Installation and Operating Guide Page 85 Figure 61. Clear EQ on selected channel Clear EQ on all channels clears third octave, bass, treble and parametric filters on all channels. Figure 62. Clear EQ on all channels AP20 Installation & Operating Guide...
Page 86: Channel Profile
AP20 Installation and Operating Guide Page 86 4.3.8 Channel Profile Menu (System) > Formats > Channel Profile Figure 63. Channel Profile Setup Screen 4.3.8.1 Current Channel Profile The current channel profile is displayed in the drop-down box under the label “Current Channel Profile”.
Page 87 Press the Delete button to complete the process, or press Cancel to quit. 4.3.8.3 Channel Names Depending how the AP20 is connected, sixteen channels are available. Channel assignments can be different in other profiles. The top title bar displays the current format and profile.
Page 88 4.3.8.4.1. Signal flow When implementing crossovers or implementing different internal routing on the AP20, the input channel numbers do not match the output channel numbers. The following explanation clarifies how the menus operate regarding the channel numbers.
Page 89 AP20 Installation and Operating Guide Page 89 4.3.8.4.2. High Pass and Low Pass Shelf The High Pass and Low Pass Shelves are for active crossover systems. The High Pass is the portion of the sound spectrum that is going to find its way to the top-end compression driver.
Page 90 M, H, and 0-9. This is used for reference for the output channel and has no functional purpose at this time. 4.3.8.4.4. Example Crossover Setup When setting up the AP20 crossovers, you will need to identify the speaker model used and obtain its technical specifications. Speaker technical specifications can usually be found on the manufacturer’s web site.
Page 91 AP20 Installation and Operating Guide Page 91 Mid Frequency Figure 69. Example – Mid Frequency Crossover Setup As shown in Figure 69, set output channel for the mid range driver. Make sure the input channel is still set to (or left channel, remember, left = channel 1 in the example).
Page 92 AP20 Installation and Operating Guide Page 92 Set the slope to 24dB/octave. Set the Crossover ID to to identify it as the high frequency output for channel three (3). Note: We also set the low pass filter to 1.2kHz, the upper range of the speaker, for added protection although it was not specified as necessary by the manufacturer.
Page 93 AP20 Installation and Operating Guide Page 93 4.3.8.5 Channel Delays Menu (System) > Formats > Channel Profile > Channel Delays Figure 72. Channel Delays Delays can be set for each of the 16 channels. Touch the Delays box under the desired channel.
Page 94: Audio Levels
AP20 Installation and Operating Guide Page 94 4.3.9 Audio Levels Menu (System) > Formats > Audio Levels Select channel(s) Figure 73. Audio Levels The Audio Levels screen is used for these functions: Set the levels. You can turn on the pink noise on any single channel to check and adjust the level.
Page 95 (blue). Digital volume should be enabled only if the system is using the digital output on the AP20. Note: Channels 1 through 16 on this screen refer to the input channels. In cases where the input is routed to a different output channel, the control represents only the input channel path.
Page 96: Network
AP20 Installation and Operating Guide Page 96 4.4 Network Menu (System) > Network Figure 74. Network Screen The Network screen displays the current network mode and IP address. It also displays whether or not the network connection is currently up or down. Use it to change between dynamic and static IP addressing.
Page 97: Automation
USB stick and then emailed to Datasat Tech Support for help with troubleshooting. Ping Test: Use for testing connectivity of the AP20 with a server. Select a network device address from the drop down menu. If available, the device address should appear in the box to the right.
Page 98: Events
AP20 Installation and Operating Guide Page 98 associated with an automation button. Menus to allow the creation of macros are provided. A Macro is a script used to perform multiple actions (see 4.5.2 Macros, page 105). 4.5.1 Events Menu (System) > Automation > Events Figure 78.
Page 99 AP20 Installation and Operating Guide Page 99 Event Type – When an event is first added the event type defaults to “No Event”, this means the event type is not configured and should be replaced with one of the other event types.
Page 100 AP20 Installation and Operating Guide Page 100 o GPO – Select a GPO to set (GPO 1-20 or Projector) by touching the dropdown menu next to “Set”. Then select an action for that GPO from the dropdown menu next to “To”.
Page 101 AP20 Installation and Operating Guide Page 101 Figure 83. Automation Edit Action screen – Conditional GPO Use descriptive variable names. Try to keep variable names short and simple. The conditional action will not work as expected if the name does not match exactly.
Page 102 AP20 Installation and Operating Guide Page 102 Serial The AP20 can be configured to allow an external device to send an RS232 command to the AP20, which, when receiving the specified serial command, will then execute any predefined action or macro.
Page 103 Page 103 Fire Alert Event A Fire Alert event will shut down the AP20 audio and display a popup on the home screen that says “Fire Alert Mode Activated” will be seen (as shown below). The AP20 audio and menus are disabled until the unit is reset from the back power button.
Page 104 Once a Fire Alert event is programmed it will be sene in the Events screen. From here you can edit or delete the event. Once the Fire Alert Mode is activated, the AP20 must be restarted from the rear panel power switch to reactivate normal operation. If the Fire Alert Mode pop up reappears after the restart, then GPI-6 must still be low.
Page 105: Macros
AP20 Installation and Operating Guide Page 105 Test by powering off the AP20 from the back, wait 10 seconds and power it back on. The events you programmed in the POWERON macro should have occurred. Note: you will not see POWERON in the EVENTS screen. It can only be seen in the Macros screen.
Page 106 AP20 Installation and Operating Guide Page 106 4.5.2.2 Delete Macro To delete a macro, highlight it on the list and select the “Delete Macro” button. Any actions contained in the Macro script must be removed before it can be deleted.
Page 107: Automation Buttons
AP20 Installation and Operating Guide Page 107 4.5.3 Automation Buttons The Automation Buttons screen shows existing buttons assigned to an Event. Information on the associated event appears below each configured button. Menu (System) > Automation > Buttons Figure 87. Automation Buttons To configure a button, touch the button to select it.
Page 108: Automation Test Screen
The input indicator turns green when there is a low signal applied to the pin. To verify that the AP20 is properly receiving an input from an external source you would need to make the external device send a low signal on that pin. Then confirm that the signal is received by the AP20 by checking if the corresponding circle turns green.
Page 109: Automation Serial
There are four pre-programmed Serial Command Modes that may be selected from the drop down list: AP20, Panastereo, 6AD, and linked AP20. AP20 - Serial automation port can be used for any AP20 serial commands as defined by the AP20 document TM-H392. Additionally, any command defined by a serial event will be processed (see section 4.5.1.1 Automation Edit Event: Serial).
Page 110: Maintenance And Troubleshooting
- volume level on both AP20s will be the same o format selection – the selected format will match on both AP20 as long as the format names are the same (note that only the format names must match).
Page 111 Using your finger, double-tap the fader level number displayed in the box at the top right corner on AP20’s touch screen. Once you double-tap, a set of green arrows will appear that can be used to adjust the main volume up or down. To increase volume, touch the up pointing arrow. To decrease volume, touch the down pointing arrow.
Page 112: Error Messages
Figure 93. USB Device Not Found If you encounter this error message, be sure you have inserted a USB device into the AP20. If a device is present, it may be malfunctioning. Replace the USB device with another to see if the problem is resolved.
Page 113: Error Booting The Ap20
************************************************************ insert USB memory stick with ap20 image ************************************************************ To solve this problem, reboot the AP20, making sure nothing is in contact with the touch screen during the boot-up process. AP20 Installation & Operating Guide Document # 9301H39200 Ver. 1.25...
Page 114 AP20 Installation and Operating Guide Version 1.25 Appendix A. Connector Pin-outs This appendix lists the pin-out of all of the connectors on the back panel of the AP20 Audio Processor. Figure 1. AP20 Rear Panel AUTOMATION GPIO – DB25F Description...
Page 115 AP20 Installation and Operating Guide Version 1.25 CONTROL (RS232)– DB9F Description Data out - TXD Data in - RXD Connected to pin 6 Chassis GND Connected to pin 4 Connected to pin 8 Connected to pin 7 N/C = No connection SERVICE PORT (RS232)–...
Page 116 AP20 Installation and Operating Guide Version 1.25 HDMI IN 1-4, OUT – HDMI Description HDMI TMDS Data 2 (+) TMDS Data 2 (Shield) TMDS Data 2 (-) TMDS Data 1 (+) TMDS Data 1 (Shield) TMDS Data 1 (-) TMDS Data 0 (+)
Page 117 AP20 Installation and Operating Guide Version 1.25 DIGITAL AUDIO IN (CH 1 – 8) – DB25F Description Standard Ch Assignment Chassis Ground AES 1/2 - AES 3/4 + C/LFE Chassis Ground AES 5/6 - LS/RS AES 7/8 + LC/RC Chassis Ground...
Page 118 AP20 Installation and Operating Guide Version 1.25 DIGITAL AUDIO OUT (CH 1 – 8) – DB25M Description Standard Ch Assignment Chassis Ground AES 1/2 - AES 3/4 + C/LFE Chassis Ground AES 5/6 - LS/RS AES 7/8 + LC/RC Chassis Ground...
Page 119 Ultra Stereo JSD-80 cinema processor. The pin-out also matches the Dolby DMA8. Datasat Digital Entertainment offers a DB25 male to female cable, 3-feet long, for hook-up (P/N 2503004100). If wiring your own cable, the following criteria must be met: 1.
Page 120 AP20 Installation and Operating Guide Version 1.25 ANALOG AUDIO OUT (CH 9 – 16) DB25M Description ANALOG GND CHANNEL 9 (+) CHANNEL 15 (-) ANALOG GND CHANNEL 11 (+) CHANNEL 16 (-) ANALOG GND CHANNEL 10 (+) ANALOG GND CHANNEL 13 (-)
Page 121 AP20 Installation and Operating Guide Version 1.25 H338 Optical Film Card Option (Rear panel plug in board). PROJECTOR 1 INPUT (Optional)– DB9F Description LT (+) LT / RT (-) LT/ RT (-) RT (+) LT / RT (-) LT / RT Analog GND...
Page 122 AP20 Installation and Operating Guide Version 1.25 Appendix B: Interface Wiring Diagrams Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 123 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 124 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 125 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 126 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 127 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 128 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 129 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 130 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: Document #: 9301H39200 Ver. 1.25...
Page 131 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: B-10 Document #: 9301H39200 Ver. 1.25...
Page 132 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: B-11 Document #: 9301H39200 Ver. 1.25...
Page 133 AP20 Installation and Operating Guide Version 1.25 Interface Wiring Diagrams Appendix B: B-12 Document #: 9301H39200 Ver. 1.25...
Page 134 AP20 Installation and Operating Guide Version 1.25 Appendix C: AP20 Wiring and Block Diagrams thru 3 HDMI 1.4a Do by/DTS Decoder Appendix C: Block Diagrams Document #: 9301H39200 Ver. 1.25...
Page 135 AP20 Installation and Operating Guide Version 1.25 Appendix D: AP20 Product Specifications Digital Audio Decoders Dolby Dolby AC3 DTS-HD Master Audio / DTS ES / DTS 5.1 / Neo:6 Signal Inputs Digital Audio Inputs Channels: 16 Connectors: Two DB25 Female (Ch1-8 and 9-16) Digital Format: AES/EBU Sample Rates: 44.1kHz, 48kHz, 96 kHz and 192kHz...
Page 136 AP20 Installation and Operating Guide Version 1.25 Signal Outputs Digital Audio Outputs Channels: 16, fully routable as to input Connectors: Two DB25 Male (Ch1-8 and 9-16) Digital Format: AES/EBU Sample Rates: 48kHz, 96 kHz and 192kHz Analog Audio Outputs Channels: 16 (fully routable as to input), common mapping with Digital Outputs...
Page 137 AP20 Installation and Operating Guide Version 1.25 Audio Delays Individual Channel Delays 0 - 1000ms Global Delay 0 –1000ms) Note: Total delay per channel not to exceed 1000ms 35mm Film Optical Soundtrack Audio Processing (with optional H338 PCB) Built-in processing for mono, A-Type and SR noise reduction.
Page 138 AP20 Installation and Operating Guide Version 1.25 Power Requirements 100-240 VAC, 50-60Hz, auto-switching 60w power consumption Hardware Dimensions 3U 19” rackmount standard Imperial - 5.25”(H) x 19.0”(W) x 15.0”(D) Shipping Weight: 30lbs Metric - 13.33 cm(H) x 48.25 cm(W) x 38.1 cm(D) Shipping Weight: 13.6kg...
Page 139 MD10H33000) with the exception of Digital Audio channels 9-16 in and out, and Analog Audio channels 9-16 out. The 8 channel AP20 may be upgraded to 16 channels by adding the H332 circuit card (P/N 9030H33200). See page AP20 8-Channel Screens The following screens differ from the standard 16-channel version.
Page 140 AP20 Installation and Operating Guide Version 1.25 System Information Screen Figure 3 – System Info Screen Menu (System) → System Info The System Info screen will display 8Chan. Routing/Crossovers Figure 4 – Routing/Crossovers Screen Menu (System) → Formats → Channel Profile → Routing/Crossovers Channel selection is limited to 8 channels.
Page 141 AP20 Installation and Operating Guide Version 1.25 Figure 5 – Channel Names Screen Menu (System) → Formats → Channel Profile → Channel Names Channel selection is limited to 8 channels. Channel Delay Screen Figure 6 – Channel Delays Screen Menu (System) → Formats → Channel Profile → Channel Delays Channel selection is limited to 8 channels.
Page 142 AP20 Installation and Operating Guide Version 1.25 Format Source Selection Screen Figure 7 – Input Select Screen Menu (System) → Formats → Input Source Only the Digital Ch 1-8 selection is available. Pressing the Digital button will not toggle to other choices. The factory default Digital Cinema format is 8 channel.
Page 143 AP20 Installation and Operating Guide Version 1.25 Octave EQ Screen Figure 9 – Third Octave EQ Menu (System) → Formats → Audio EQ Setup → Third Octave EQ Channel selection is limited to 8 channels. Parametric EQ Screen Figure 10 – Parametric EQ Menu (System) →...
Page 144 AP20 Installation and Operating Guide Version 1.25 16-Channel Upgrade (H332 Card) The 8 channel AP20 may be upgraded to 16 channels by adding the H332 circuit card. Order P/N 9030H33200 latest version. H332 Card Installation Tools required: Phillips head #2 screw driver Caution: The H332 card contains parts that are static sensitive.
Page 145 This card offers two inputs (Projector 1 & 2), see Figure 1 below. Both inputs have an LED to indicate which input is active. The automation in the AP20 must be programmed to switch the inputs at the proper time. In addition to these inputs, there are two Lt/Rt test points. These are BNC type connectors that are used for alignment of the projectors optics.
Page 146 Turn off the AP20’s rear panel power switch and unplug the power cord. • Remove one of the three cover plates from the AP20 option slots. All slots are identical. • Slide the H338 card into the card guides of the option slot and gently push the card into its mating connector.
Page 147 6 channel assignments and trim values flat. If the H338 card is not factory installed, Optical formats must be created in the AP20 before the H338 can be used. The optical format must have the analog input source selected as Optical. The H338 card supports standard optical film soundtrack formats: Mono, A-type and SR-type.
Page 148 AP20 Installation and Operating Guide Version 1.25 F3.2. Assign Optical Formats to Format Buttons After creating the optical formats, they may be assigned to “Format Buttons”. The format buttons will then appear on the Home screen and be available for selection. In Figure 4 below, SR is selected.
Page 149 AP20 Installation and Operating Guide Version 1.25 F3.3. Input Source Selection Select the Input Source button. This will open the Input Select screen. Each of the optical formats must be set to have Optical selected as their input source. In the example in Figure 6 below, SR will have its input source set to Optical.
Page 150 Inputs from the film are on the left. The resulting channels are on the right side, and are internal to the AP20. Note that these are not necessarily the output channels as they and may be routed on the AP20 output (see Section 2.9.4 Assign Channels on AP20 in this manual).
Page 151 AP20 Installation and Operating Guide Version 1.25 In this example, left total (LT) and right total (RT) are the inputs. Outputs are: 1L = channel 1 is left, 2R = channel 2 is right, 3C = channel 3 is center, 4Lfe = channel 4 is bass, 5Ls = channel 5 is left surround, and 6Rs = channel 6 is right surround.
Page 152 LED voltage and adjust it if necessary, as per the manufacturer’s recommended procedure. F4.3. Wiring and Connections Projector 1 & 2 inputs on the AP20 are 9-pin female D-connectors. See Figure 8 below for pin assignments. Input from the solar cell is a 9-pin Male D-connector. PIN NO.
Page 153 The right channel is nearest the edge of the film. To confirm proper wiring, while observing the projector output on a RTA or the AP20 setup screen, place a business card or similar object to block the side of the cell nearest the edge of the film. You should detect a large drop in the right channel level.
Page 154 Allen/Hex Wrenches, small screw driver etc. On the AP20 select one of the optical formats in the home screen, next select Menu (System) → Formats → Format Options → Film Options → Film Setup. You should now be in the Film Card Setup screen as shown in .
Page 155 Consult your projector’s manual for more information. To close this window, press Dismiss. To manually adjust levels, select the button below the left input level bar and use the AP20 front panel adjustment knob to increase or decrease this level until it meets the reference line.
Page 156 Figure 14 – Crosstalk using Cat 97 test film Note: while running the CAT 97 test film you can also select Azimuth in the AP20’s optical set up screen. If alignment is correct you should be able to observe a cross on the screen as shown in Figure 15.
Page 157 Correct Figure 16 – Azimuth This can also be viewed on the AP20 screen by going to Menu (System) → Formats → Format Options → Film Options → Film Setup and Selecting Azimuth (see Figure 15). When Azimuth is selected, on the right a pictorial of the azimuth adjustment is shown.
Page 158 AP20 Installation and Operating Guide Version 1.25 Figure 17 – Focus After the flattest response is achieved by adjusting the projector optics, the final slit loss correction is made using the Parametric Filter Settings, see Figure 18. F4.4.5. Slit Loss EQ When Slit Loss EQ is selected a graph of the slit loss adjustment is shown on the right of the screen (see Figure 18 below).
Page 159 Soundtrack Input Figure 19 – Digital Soundtrack Input None is use when the AP20 analog and digital input connectors are not used for the film digital soundtrack. Digital Channels 1->8 select this if the film digital soundtrack player is connected to the AP20 Digital Input channels 1-8 connector.
Page 160 RTA. Select an optical format on the AP20, enable pink noise on the center channel, and note the level and low frequency roll off displayed on the RTA. Select the appropriate Low Pass Filter setting by pressing that button and using the fader knob to make any changes required to match the low pass filter to the roll off measured.
Page 161 Next turn on the subwoofer channel, enable pink noise on the LFE channel, and then select the Bass Gain by pressing the <Gain> button. Use the AP20 fader knob, or up and down keys when using a laptop, to adjust the Bass Gain to match the Center channel level previously noted on the RTA display.
Page 162 Version 1.25 Appendix G: Connecting Two AP20 units Two AP20 units can be linked together serially. When this is done the two units work in unison locking their format, fader level, and mute selection. Both AP20 units must have matching format names. The names must match exactly although their format profiles may be different.

Datasat AP20 Installation And Operating Manual

Part 1: Operation

Ap20 Installation and Operating Guide

Formats

Network

Automation

Maintenance and Troubleshooting

Routine Maintenance

Troubleshooting

Error Messages

Quick Links

Chapters

Troubleshooting

Need help?

Questions and answers

Related Manuals for Datasat AP20

Summary of Contents for Datasat AP20

Table of Contents
