1.0 Operating AP25
1.1 How-To Procedures – Operations
ACTIVITY
Turn Power ON
Turn Power OFF
Adjust volume
Select a format
Identify the selected
format
Mute the AP25
Unmute the AP25
View monitor settings
Select monitor
channel(s)
Change monitor volume
Mute the monitor
Unmute the monitor
AP25 Installation & Operating Guide
AP25 Installation and Operating Guide
INSTRUCTIONS
Press and release the power button on the front panel. If the unit will not
power up, be sure that the rear panel power switch is ON and the unit is
plugged into a working AC outlet protected by a surge protector. See
Powering ON the AP25 Processor, page 16.
Press and release the power button on the front panel.
Turn the master fader knob on the front panel to adjust volume on all
channels. Turn clockwise to increase volume. See Adjusting the Fader,
page 18.
Touch the desired format in the bottom row of the AP25 display. If the
format you want is not shown, then that format is not available. See The
Home Screen, page 17.
The current format is highlighted in the bottom row of the AP25 display.
Touch the MUTE button. If successful, the MUTE button will change to
"MUTED" and its background color will change to red. See Adjusting the
Fader, page 18.
Touch the red MUTED button. If successful, the button will change to
"MUTE" and its background color will be gray.
Touch the MONITOR button. The Monitor window will display. It will
automatically disappear after 30 seconds. See Booth Monitor Volume,
page 19.
Touch the MONITOR button. The Monitor window will display. Then
touch the MIX button and select the channel(s) you want to hear in the
monitor. When finished, touch the CLOSE button. See Booth Monitor
Volume, page 19.
Touch the MONITOR button. The Monitor window will display. Then
touch the + or – button until the desired volume is set. The window will
automatically disappear after 30 seconds. See Booth Monitor Volume,
page 19
Touch the MONITOR button. The Monitor window will display. Then
touch the MUTE button in the monitor window. The MUTE button will turn
red. Note that the Monitor button to the left of the window also turns red
to indicate a muted state. The window will automatically disappear after
30 seconds.
Touch the MONITOR button. The Monitor window will display. Then
touch the MUTE button in the monitor window. The MUTE button will turn
from red to gray. Note that the Monitor button to the left of the window
also turns gray to indicate the unmuted state. The window will
automatically disappear after 30 seconds
