Datasat AP25 Installation And Operating Manual page 55

Menu (System) > Update System Software
Figure 27. System Software Update Screen
4.2.2.1 Update System Software from Network
The following steps describe how to update your AP25 software through the internet.
Using the Select Update Source dropdown menu, choose Main Server, or Secondary Server. Both
will provide the same information. If you successfully connect to the server a list will appear of all
available software versions. The most current will always be at the top of the list. Use the adjustment
knob to highlight the desired software version.
The current version of software loaded on the AP25 is displayed under Current on the right side of the
screen. The highlighted software version, will display under Selected on the right side of the screen.
Once the desired version is confirmed, press the Start Update button
Note: If you select an older version of software than is currently loaded on the AP25, you will
receive a warning message and be asked to verify that you wish to continue.
Note: Your AP25 must already have an active internet connection in order to update software
through the internet. If you receive a message "failed to get file list" your internet connection
is not working and the AP25 is unable to connect with the server.
Connection will take place automatically, and the following screen will appear.
Figure 28. Downloading Software Update via Internet
Depending upon your connection speed, downloading, decompressing, and installing files could take
anywhere from 10 minutes to less than a few minutes to complete. When the installation process is
finished, the AP25 will automatically reboot.
AP25 Installation & Operating Guide
AP25 Installation and Operating Guide
Document # 9301H79500 Ver. 1.00
Page 55
