Figure 6-2 Ac Power Switch And Plug - Sun Microsystems SPARCserver 1000 Service Manual

AC power switch
AC plug
6.2 Restarting the System
Figure 6-2 AC Power Switch and Plug
Note – As the system starts up, watch for error messages from the POST
diagnostic program. If a terminal is not connected, locate a TTY terminal before
continuing the installation. See Chapter 3, Section 3.6, "Connecting a Terminal
to the System Master" for connecting and setting the terminal.
1. Begin with a safety inspection of the system.
a. Ensure the key switch on the front panel is in the Standby position.
See Figure 6-1.
b. Ensure the AC power switch on the system rear is off.
c. Verify the power cord is plugged into the server and a wall socket.
2. Turn on the TTY terminal.
3. Turn on the AC power switch on the rear panel.
4. Turn the key switch to the on position.
See Figure 6-3. You should see and hear several things happen:
• Fans begin turning.
Powering Off and On
6
6-3
