10.5 SIMMs and NVSIMMs

10-16
9. Replace and tighten back panel screws to secure the SBus card in place.
Note – For Ethernet type SBus cards, you may want to verify SBus card
operation at this point. To per form the link integrity test, refer to Section 3.9,
"Disabling and Enabling the Link Integrity Test."
Three SIMM options exist; two are DRAM SIMMs. The third is a nonvolatile
SIMM (NVSIMM). (See Figure 10-12.) All three SIMM types are removed and
replaced in the same manner. Table 10-1 summarizes the SIMM variations.
Table 10-1 SIMM Variations
Capacity Type
8 Mbyte DRAM
8 Mbyte DRAM
32 Mbyte DRAM
32 Mbyte DRAM
1 Mbyte NVSIMM (featuring battery backup power)
Note – These SIMMs were designed for the SPARCserver 1000 system and are
not interchangeable with other types of SIMMs.
Type A 8 Mbyte SIMMs are interchangeable with Type B 8 Mbyte SIMMs. The
two 32 Mbyte SIMM types may also be interchanged. However, SIMMs of
different capacities cannot be interchanged within a group. To select the proper
SIMM socket locations, See Appendix C, "SIMMs and Jumpers."
SPARCserver 1000 System Service Manual—June 1996
Part Number Appearance
501-1817-xx Type A
501-1817-xx Type B
501-2196-xx Type A
501-2196-xx Type B
501-2197-xx Type C
