SPARCserver 1000 System Board Manual
Sun Microsystems Computer Corporation
2550 Garcia Avenue
Mountain View, CA 94043
U.S.A.
Part No: 801-2900-12
Revision A, October 1994

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPARCserver 1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems SPARCserver 1000

Summary of Contents for Sun Microsystems SPARCserver 1000

  • Page 1 SPARCserver 1000 System Board Manual Sun Microsystems Computer Corporation 2550 Garcia Avenue Mountain View, CA 94043 U.S.A. Part No: 801-2900-12 Revision A, October 1994...
  • Page 2 The product described in this manual may be protected by one or more U.S. patents, foreign patents, or pending applications. TRADEMARKS Sun, the Sun logo, Sun Microsystems, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and certain other countries. UNIX is a registered trademark in the United States and other countries, exclusively licensed through X/Open Company, Ltd.

  • Page 3: Table Of Contents

    Contents Preface ..........1.
  • Page 4 A.1 SIMM Configuration ......A-1 A.1.1 SPARCserver 1000 and SPARCserver 1000E System Board Rules .
  • Page 5 A.2 Jumper Configuration ......A-3 B. Connector Pinouts........B.1 Connector Locations.
  • Page 6 SPARCserver 1000 System Board Manual—October 1994...
  • Page 7 Figures Figure 1-1 End and Side Views of the System Board ....Figure 1-2 System Board Block Diagram ......Figure 2-1 Removing the System Board Retaining Screws .
  • Page 8 Figure C-5 NVSIMM Jumper Locations......viii SPARCserver 1000 System Board Manual—October 1994...
  • Page 9 Tables Table 1-1 Safety Precautions ........Table 1-2 Replaceable Units for the System Board .
  • Page 10 SPARCserver 1000 System Board Manual—October 1994...

  • Page 11: Preface

    This system board manual is written for a trained service provider who intends to install the SPARCserver 1000™ or SPARCserver 1000E™ system board. In general, the term SPARCserver 1000 refers to both the SPARCserver 1000 and the SPARCserver 1000E system board. Where the SPARCserver 1000E is different, this is explicitly noted.

  • Page 12: Related Documentation

    Part Number Diagnostics Open Boot PROM 2.x User‘s Guide 800-5674-xx Open Boot Command Reference 800-6076-xx User’s Guides SPARCserver 1000 Storage Device User’s Guide 801-2198-xx POST User’s Guide 800-7487-xx System and Network Administration for the Sun Workstation 800-1323-xx Service, System SPARCserver 1000 System Service Manual...
  • Page 13 Notes, Cautions, and Warnings Warning – The SPARC module has a hot surface. Avoid contact. Surfaces are hot and may cause personal injury if touched. Warning – This equipment contains lethal voltage. Accidental contact can result in serious injury or death. Caution –...
  • Page 14 SPARCserver 1000 System Board Manual—October 1994...

  • Page 15: Before You Start

    Before You Start This chapter covers the procedures and information you need to know before you begin installation or service on your SPARCserver 1000 system. 1.1 Tools Required • Sun ESD mat and grounding wrist strap • #0 Phillips screwdriver •...

  • Page 16: Safety Precautions

    Install airflow restrictor boards in all unused card cage slots. Unused, open slots restrictor boards and overheating severely reduce the cooling capability of the system and can lead to equipment (filler panels) damage from overheating. SPARCserver 1000 System Board Manual—October 1994...

  • Page 17: System Board Description

    1.3 System Board Description Figure 1-1 shows the locations of major components on the system board. SIMMs SBus connectors SuperSPARC modules Figure 1-1 End and Side Views of the System Board All system boards are essentially the same; no jumper changes are necessary. System boards can be moved to any slot, especially during troubleshooting.

  • Page 18: System Board Block Diagram

    1.4 System Board Block Diagram Figure 1-2 is a block diagram of the system board. The SuperSPARC modules, SIMMs, and optional SBus cards are removable and can be replaced or moved to another SPARCserver 1000 system board. LEDS JTAG Control...

  • Page 19: Replaceable Units

    The following items are system board components that can be replaced at customer’s site. Table 1-2 Replaceable Units for the System Board Part Number SPARCserver 1000 System board, 0 processors, 0 SIMMs 501-2336 SPARCserver 1000E System board, 0 processors, 0 SIMMs 501-2668 SuperSPARC module...
  • Page 20 SPARCserver 1000 System Board Manual—October 1994...

  • Page 21: Removing And Replacing System Boards And Assemblies

    Removing and Replacing System Boards and Assemblies This chapter provides information on removing or replacing: • System boards • SuperSPARC modules • SBus cards • SIMMs and NVSIMMs • OpenBoot PROMs • TOD/NVRAM 2.1 Handling System Boards and Assemblies Caution – The system chassis power must be turned OFF, and the AC power cord must remain plugged in to ensure a proper ground.

  • Page 22: System Board

    Disconnect any keyboard, SCSI, network, or other cables connected to the back panel. Label cables to ease reconnection later. 8. Remove the two screws that hold the system board to the card cage. Refer to Figure 2-1. Set the screws aside for later reinstallation. SPARCserver 1000 System Board Manual—October 1994...

  • Page 23: Figure 2-1 Removing The System Board Retaining Screws

    Retain- screws Figure 2-1 Removing the System Board Retaining Screws 9. Pull the curved ends of both extraction levers outward simultaneously to release the board from the backplane connectors. Refer to Figure 2-2. Removing and Replacing System Boards and Assemblies...

  • Page 24: Replacement

    11. Place the board on the ESD mat or in an antistatic bag. 2.2.2 Replacement Note – To select a card cage slot for the system board, refer to Appendix C, “General Rules for System Configuration.” SPARCserver 1000 System Board Manual—October 1994...

  • Page 25: Using Standoffs

    1. Open the protective packaging and take out the system board. 2. Carefully insert the board in the proper slot in the card cage, ensuring that the board does not slip out of the left and right card guides. The component side of the board must face up. 3.

  • Page 26: Supersparc Modules

    2.4 SuperSPARC Modules Each system board can have two SuperSPARC modules, A and B. Refer to Figure 2-4. To select the proper location for a SuperSPARC module, refer to Appendix C, “General Rules for System Configuration.” SPARCserver 1000 System Board Manual—October 1994...

  • Page 27: Removal

    SuperSPARC module A SPARC connectors SuperSPARC module B Figure 2-4 SuperSPARC Modules A and B Installed 2.4.1 Removal SuperSPARC module A is mounted on four standoffs on the system board. SuperSPARC module B is mounted like an SBus card, the connector end mounts on standoffs but the back panel end slides onto the lip of a back panel filler plate.

  • Page 28: Supersparc Module A

    Note – It may be necessary to remove either SuperSPARC module A or the SBus card in slot 1 to get a firm grip on module B. A firm grip is necessary to remove the module from the connector without breaking the connector. SPARCserver 1000 System Board Manual—October 1994...

  • Page 29: Replacement

    Figure 2-5 Installing SuperSPARC Module B 4. Place the SuperSPARC module in an antistatic bag. 2.4.2 Replacement 1. Unlock the standoffs for the chosen location if they are not already unlocked. Pull up the tip insert of a standoff to unlock it. Refer to Figure 2-3. 2.

  • Page 30: Sbus Card

    6. Press down on the tip insert of each standoff to lock the module in place. 2.5 SBus Card The system board has three SBus card locations. Refer to Figure 2-6. To select the location for an SBus card, refer to Appendix C, “General Rules for System Configuration.” 2-10 SPARCserver 1000 System Board Manual—October 1994...

  • Page 31: Removal

    SBus connectors SBus card 0 SBus card 1 SBus card 2 Figure 2-6 SBus Card Locations 2.5.1 Removal 1. Remove the two screws that secure the SBus card to the back panel. Save the screws for installation of a replacement SBus card or a filler panel. 2.

  • Page 32: Installation Or Replacement

    Note – If the new SBus card has an adapter plate (refer to Figure 2-8), remove the plate by performing the procedures in Section 2.5.2.1. If the SBus card does not have an adapter plate, go instead to Section 2.5.2.2. 2-12 SPARCserver 1000 System Board Manual—October 1994...

  • Page 33: Preparing For Installation

    2.5.2.1 Preparing for Installation 1. Open the protective packaging and take out the SBus card. 2. Remove the adapter bracket from the SBus card rear panel. Refer to Figure 2-8. Using a #0 Phillips screwdriver, remove the two screws securing the adapter to the card rear panel. The adapter bracket and the screws are not needed for this installation.
  • Page 34 SBus card. In the event of “loss of carrier” or “not responding” problems, check the status of the link enable on both the SBus card and the hub. 2-14 SPARCserver 1000 System Board Manual—October 1994...
  • Page 35 Jumper J0302 Springfinger Jackscrews Back panel Phillips screw Figure 2-10 DSBE/S SBus Card J0302 Figure 2-11 FSBE/S SBus Card Removing and Replacing System Boards and Assemblies 2-15...

  • Page 36: Installing An Sbus Card

    Caution – Do not rock the card onto the socket; the plastic connector housing may break. 7. Press each corner of the SBus card to ensure that it rests on the collar of the standoff. 2-16 SPARCserver 1000 System Board Manual—October 1994...

  • Page 37: Dsimms And Nvsimms

    1Mbyte NVSIMM (battery-backed) 501-2197 Note – These SIMMs were designed for the SPARCserver 1000 system and are not interchangeable with other types of SIMMs. Type A 8 Mbyte SIMMs are interchangeable with Type B 8 Mbyte SIMMs. The two 32 Mbyte SIMM types many also be interchanged. However, SIMMs of different capacities cannot be interchanged within a group.

  • Page 38: Removal

    Figure 2-14 NVSIMM (Battery Side) 2.6.1 Removal To remove a SIMM from a system board: 1. Locate the faulty SIMM by matching the location number displayed by POST with the J-number shown in Figure 2-15. 2-18 SPARCserver 1000 System Board Manual—October 1994...

  • Page 39: Figure 2-15 Simm Socket Locations

    J4300 J4100 J3900 J3700 J3500 J3300 Group 3 Group 3 Group 2 Group 2 J3100 J2900 Group 1 Group 1 Group 0 Group 0 J4200 Group 3 Group 3 J4000 Group 2 Group 2 Group 1 Group 1 J3800 J3600 Group 0 Group 0 J3400...

  • Page 40: Figure 2-16

    Refer to Figure 2-17. Unlock additional SIMMs to remove the first SIMM Figure 2-17 Creating Space to Remove a SIMM 5. Remove the SIMM from the socket and place it in an antistatic bag. 2-20 SPARCserver 1000 System Board Manual—October 1994...

  • Page 41: Replacement

    2.6.2 Replacement Note – Do not mix 8 Mbyte SIMMs with 32 Mbyte SIMMs (or 1 Mbyte NVSIMMs) in the same group. (However, SIMMs from different manufacturers are interchangeable in a single group if the SIMMs all have the same capacity and speed.) Caution –...

  • Page 42: Nvsimms

    Figure 2-18 NVSIMM Jumper Locations Caution – After you turn the battery ON do not move or remove the jumper. Moving the jumper will cause the lose of any data contained in the NVSIMM. 2-22 SPARCserver 1000 System Board Manual—October 1994...

  • Page 43: Openboot Proms

    Once the jumper is in the ON position, proceed with the installation or removal as described in the preceding sections. 2.7 OpenBoot PROMs Use this procedure for Boot PROM upgrades. Refer to Figure 2-19 for the PROM socket locations. Pin one is at the upper left corner for all the PROMs. 2.7.1 Removal 1.

  • Page 44: Tod/Nvram Ic

    2. Use an IC extractor tool to remove the IC. Refer to Figure 2-20 to locate the TOD/NVRAM IC. 3. Place the IC on antistatic foam plastic in an antistatic package for storage or possible reuse. 2-24 SPARCserver 1000 System Board Manual—October 1994...

  • Page 45: Replacement

    2.8.2 Replacement 1. Verify the correct IC location. 2. Position the IC carefully on the socket, and partially seat the IC. 3. Ensure that the IC pins are not bent, then press firmly to seat the IC in the socket. Caution –...

  • Page 46: Restarting The System

    4. Watch the boot display to confirm that all processors and the newly installed or replaced hardware are recognized. 5. After the system finishes booting, the login prompt is displayed. Log in and resume operation. 2-26 SPARCserver 1000 System Board Manual—October 1994...

  • Page 47: Configuring Simms And Jumpers

    A.1 SIMM Configuration The SPARCserver 1000 system board has one bus, and all SIMM groups are attached to this bus. The SIMM slots on each board, sixteen in all, are divided into four groups of four slots each. The SIMM groups are numbered from 0 to 3.

  • Page 48: Figure A-1 Simm Group Locations On The System Board

    J3600 Group 0 Group 0 J3400 J3200 J3000 J2800 Figure A-1 SIMM Group Locations on the System Board The SIMMs on a system board are divided into four groups, as summarized in Table A-1. SPARCserver 1000 System Board Manual—October 1994...

  • Page 49: Locating A Failing Simm

    Table A-1 SIMM Group Organization Group Location Group 0 J2800, J2900, J3000, J3100 Group 1 J3200, J3300, J3400, J3500 Group 2 J3600, J3700, J3800, J3900 Group 3 J4000, J4100, J4200, J4300 A.1.2 Locating a Failing SIMM When a SIMM (or NVSIMM) fails during the power on self-tests (POST), the SIMM location number (also known as J or U-number) and system board card cage slot number are displayed on the TTY terminal and saved in /usr/adm/<filename>...

  • Page 50: Figure A-2 Jumper Locations On The System Board

    J1100 J1101 J1201 J1200 Figure A-2 Jumper Locations on the System Board SPARCserver 1000 System Board Manual—October 1994...

  • Page 51: Connector Pinouts

    Connector Pinouts This appendix lists pinouts of connectors on the system board: • Keyboard and mouse connector • Serial port connectors A and B • SBus slots 1, 2, and 3 • Backplane connector • SuperSPARC module slots A and B B.1 Connector Locations Figure B-1 shows the backpanel and the top of the system board.

  • Page 52: Keyboard And Mouse Connector

    SCSI connector Keyboard connector Serial connectors SuperSPARC module connectors LEDs Figure B-1 Back and Top Views of the System Board B.2 Keyboard and Mouse Connector GND RDKBRD TDKBD Figure B-2 Keyboard/Mouse Connector Pinout SPARCserver 1000 System Board Manual—October 1994...

  • Page 53: Serial Port Connectors

    B.3 Serial Port Connectors TXDA TXDB RXDA RXDB RTSA RTSB CTSA CTSB DSRA DSRB DTRB 20 DTRA 20 DCDA DCDB Serial port connector A Serial port connector B BAR CODE End view Figure B-3 Serial Port A and B Connector Pinouts Connector Pinouts...

  • Page 54: Sbus Connectors

    59 SB_D<11> 91 SB_PA<23> 28 SBIntR_L<6> 60 GND 92 GND 29 SB_PA<0> 61 SB_D<13> 93 SB_PA<25> 30 SB_PA<2> 62 SB_D<15> 94 SB_PA<27> 31 SB_PA<4> 63 SB_D<17> 95 SB_Rst_L<0> 32 SBLErr_L 64 VCC 96 FS_VDD SPARCserver 1000 System Board Manual—October 1994...

  • Page 55: Table B-2 Sbus Connector 2 (Connector J4902

    Table B-2 SBus Connector 2 (Connector J4902) Section 1 Section 2 Section 3 33 SB_PA<6> 65 SB_D<18> SB_BR_L<1> 34 SB_PA<8> 66 SB_D<20> SB_Sel_L<1> 35 SB_PA<10> 67 SB_D<22> SBIntR_L<7> 36 SB_Ack<0> 68 GND SB_D<0> 37 SB_PA<12> 69 SB_D<24> SB_D<2> 38 SB_PA<14> 70 SB_D<26>...

  • Page 56: Table B-3 Sbus Connector 3 (Connector J4903

    59 SB_D<11> 91 SB_PA<23> 28 SBIntR_L<20> 60 GND 92 GND 29 SB_PA<0> 61 SB_D<13> 93 SB_PA<25> 30 SB_PA<2> 62 SB_D<15> 94 SB_PA<27> 31 SB_PA<4> 63 SB_D<17> 95 SB_Rst_L<2> 32 SBLErr_L 64 VCC 96 FS_VDD SPARCserver 1000 System Board Manual—October 1994...

  • Page 57: Backplane Connector

    B.5 Backplane Connector The system board has one backplane connector. Table B-4 shows the connector location and lists the function of each connector pin. Table B-4 Backplane Connector (Connector J0200) (1 of 2) Section 1 Section 2 Section 3 Section 4 MSTRPR_L SYTAS SYTCK...
  • Page 58 SY1GTS_L BDID<0> BDID<1> SYSECT Fan_Fail AC_Fail DiagMode_L SyPwrRst_L TXDA SYSRST_L SYRST_L TPIM TPOP TPOM TPIP SCRST SCSD<0> SCSEL SCIO SCSD<1> SCSD<2> SCSD<3> SCSD<4> SCSD<5> SCSD<6> SCSD<7> SCDP SCMSG SCATN SCBSY SCACK SCREQ SCCD TERMPWR SPARCserver 1000 System Board Manual—October 1994...

  • Page 59: Supersparc Module Connectors

    B.6 SuperSPARC Module Connectors SuperSuperSPARC module connectors A and B have identical pinouts. Table B-5 SuperSPARC Module Connectors (Connectors J2000 and J2300) (1 of 2) Name Name Blade Name BWBdTdo 51 BdTms BdTdo 52 BdPwrRst_L BDTck 53 BootData<7> BootData<6> 54 BootData<5> BootData<4>...
  • Page 60 92 XData<57> 43 XData<58> 93 XData<59> 44 XData<60> 94 XData<61> 45 XData<62> 95 XData<63> 46 BootCmd<2> 96 BootData<3> 47 BootData<2> 97 BootData<1> 48 BootData<0> 98 CCErr_L 49 BdRst_L 99 BootCmd<1> 50 BootCmd<0> 100 XGnt_L B-10 SPARCserver 1000 System Board Manual—October 1994...

  • Page 61: General Rules For System Configuration

    General Rules for System Configuration This appendix lists recommended priorities and locations for: • System boards • SuperSPARC modules • SBus cards • SIMMs • Drive IDs • SCSI cables • Ethernet cables • Video cables C.1 Selecting Installation Locations Each component described in this appendix has a specific recommended location.

  • Page 62: Supersparc Modules

    B connectors, starting with the system board in slot 0. SuperSPARC module A SPARC connectors SuperSPARC module B Figure C-1 Locations of SuperSPARC Modules The example in Table C-1 shows how to distribute four SuperSPARC modules on three system boards. SPARCserver 1000 System Board Manual—October 1994...

  • Page 63: Sbus Cards

    Table C-1 Example of Connector and Slot Priorities System Board Slot 0 System Board Slot 1 System Board Slot 2 Connector A Full Full Full Connector B Full – – C.1.3 SBus Cards Each system board has three SBus slots. Each SBus card mounts on standoffs above the system board.

  • Page 64: Simms

    1 FSBE/S C.1.4 SIMMs The SPARCserver 1000 system has three SIMM options. Two types of DRAMs, high-density and low-density, are available as well as nonvolatile NVSIMMs. The 8 Mbyte (low-density) SIMMs use 1 Mbit by 4 bit DRAMs. Two vendors are used, so there is a slight variation in physical appearance between the two products.
  • Page 65 SIMM — Vendor 1 Capacity Type 8 Mbyte DRAM 501-1817 32 Mbyte DRAM 501-2196 SIMM — Vendor 2 Capacity Type 8 Mbyte DRAM 501-1817 CBS - CBS - 32 Mbyte DRAM 501-2196 NVSIMM Capacity Type Battery 1Mbyte NVSIMM 501-2197 Figure C-3 SIMMs and NVSIMM The system board has 16 SIMM sockets physically divided into two rows of eight.

  • Page 66: Nvsimms

    Before installing NVSIMMs, first activate the battery to insure data retention. To activate the battery: 1. Locate the jumper on the right side of the NVSIMM. Refer to Figure C-5. 2. Move the jumper to the battery on position. SPARCserver 1000 System Board Manual—October 1994...

  • Page 67: Connecting Cables

    C.2.2 Ethernet Cables The main network cable must be connected to the on-board Ethernet connector on system board 0. Refer to instructions provided with your Ethernet transceivers for additional connection information. The SPARCserver 1000 system supports twisted-pair Ethernet installations. C.2.3 Video Cables Only one CGSIX interface is allowed per system.
  • Page 68 SPARCserver 1000 System Board Manual—October 1994...
  • Page 69 Index backplane connector, B-7 disable Link Integrity Test, 2-14 block diagram of system board, 1-4 DSBE/S card preparing, 2-14 boot PROM - see "OpenBoot PROM" DWIS/S card preparing, 2-14 card retainer, SBus, 2-13 configuring enable Link Integrity Test, 2-14 jumpers, A-1 SIMMs, A-1 connecting Ethernet cables, C-7...
  • Page 70 A-1 serial ports, B-3 unlocking, 2-20 POST, A-3 standoff preparing a new SBus card, 2-13 lock and unlock, 2-6 using, 2-5 SuperSPARC module connectors, B-9, C-2 releasing the board, 2-3 location, C-2 Index-2 SPARCserver 1000 System Board Manual—October 1994...
  • Page 71 removing, 2-7 replacing, 2-9 system board block diagram, 1-4 description, 1-3 field-replaceable unit, 1-5 illustration, 1-3 jumper configuration, A-3 removing, 2-2 rules, A-1 SIMM memory rules, A-1 system master, 1-3, C-1 tools required, 1-1 tty terminal, set-up, 2-26 unlocking SIMM, 2-20 u-number, SIMM memory, 2-18 using standoffs, 2-5 Index-3...
  • Page 72 Index-4 SPARCserver 1000 System Board Manual—October 1994...
