7.1 Front Panel
Internal Access
This chapter provides the information necessary to prepare the system for
service after the system has been powered off.
To access the SPARCserver 1000 SCSI tray subassembly, the power supply, and
the backplane remove the front panel and the EMI shield. To access the other
side of the backplane, remove all system boards and air restrictor panels.
You must remove the front panel before you can remove the EMI shield. The
front panel rests in a groove cut on the top front edge of the chassis.
To remove the front panel:
1. Remove the key from the key switch.
2. Push up on the latch located on the bottom, center of the front panel.
Place your fingers under the arrow embossed on the front panel and push
up to release the latch. See Figure 7-1.
