Appendix A - Examples
AF626E5A14F19C025B7CD1EF1456A31DDFDF560A9500030000000120039DDFDF570180
DFDF580106F782007FDFDF4001015F25031201015F24031401315F2A0208269F020600
00000002009F0607A00000000410109F1C0831313232333334349F3901059C01009F34
035E03005F5701305F3401005F2009544553542F43415244DFDF4D263B353431333030
303034303030313531333D303131343030303030303030303030303030303F
The value in data block F9 starts with tag DFDF54, which according to Appendix D MagTek Custom
EMV Tags and section 3.6.6, provides the MAC KSN. Its length is 0x0A (as described above, a value
smaller than 0x7F means the length is indicated by a single byte), so the next 10 bytes provide MAC
KSN 9500030000000120039D.
Next in the value of data block F9 is another tag, DFDF55, length 0x01, value 0x82. According to
Appendix D MagTek Custom EMV Tags and section 3.6.6, this indicates the MAC encryption type is
DUKPT key.
The next tag is DFDF25 of length 0x08, giving the IFD Serial Number 98CE04611018060D.
The next tag is FA (generic data container), and 0x82 indicates the next two bytes 0x01A0 are the
length, giving a 416 byte value: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 value of data object FA begins with tag F0, which Appendix D MagTek Custom EMV Tags and
section 3.6.6 indicate is transaction results. Its length 0x82019C gives a 412 byte value: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