3 - Command Set
Bit 7
Byte 1 Operation Status (see Appendix C Status and Message Table)
Bytes 2..11 MSR KSN
Bytes 12..19 Encrypted Cardholder Data block (ECDB)
The ECDB contains the information that was requested by the host with Command 0x14 - Request
Cardholder Data Entry (for example, if the host requested the cardholder's zip code, this report would
return just the zip code data). After decryption, The 8-byte Cardholder Data Block is divided into 16
four-bit nybbles, as specified in the tables below. Each nybble contains one of the following:

C: Control field
o 0100=SSN
o 0101=Zip Code
o 0110=Birth Date

N: Data length

P: Cardholder data digit from 0000 (decimal 0) to 1001 (decimal 9)

R: Filled random number

P/R: If the Birth Date data length is 6 (MMDDYY format), the positions marked P/R will be filled
with random numbers (R); if the Birth Date data length is 8 (MMDDYYYY format), those positions
will contain the rightmost two characters of the birth year (P).
Table 3-49 - Report 0x21 Cardholder Data Block Format
8-
Bits 0-3 4-7
11
SSN C N P
Zip
C N P
code
Birth
C N P
date
Activat
C N P
ion
Code

3.5.3 Report 0x22 - Card Status Report

This event is triggered by Command 0x03 - Request Swipe Card or Command 0xA2 - Start EMV
Transaction, which will cause the device to send Operation Status, Card Status, and Card Type to the
host.
Table 3-50 - Usage Table for Report 0x22
Bit 7
Byte 0 0x22
Byte 1 Operation Status (see Appendix C Status and Message Table)
Byte 2 Card Status (see Appendix C Status and Message Table)
DynaPro Mini| PIN Encryption Device | Programmer's Manual (Commands)
6 5
12 16 20 24
15 19 23 27
P P P P
P P P P
P P P P
P P P R
6 5
Page 61 of 128 (D99875629-43)
4 3
28 32 36 404
31 35 39 3
P P P P
R R R R
P P/R P/R R
R R R R
4 3
2 1
444 48 52 56
7 51 55 59
R R R R
R R R R
R R R R
R R R R
2 1 0
0
60
63
R
R
R
R
