3 - Command Set
information about the bootloader is available in document 99200071 MNL DYNALEX
BOOTLOADER.
To send new file data to the device, follow these steps:
1) Issue Command 0x10 - Send Big Block Data to Device to send new file data to the device
2) Issue Command 0x17 - Update Device to request the device to validate and perform an update using
the file data with the correct parameters.
If an error occurs, the device will terminate the command and report the error in ACKSTS of Command
0x01 - Response ACK. For a full list of error codes, see Appendix C Status and Message Table, Table
3-76.
Table 3-24 - Usage Table for Command 0x17
Bit 7
Byte 0 0x17
Byte 1 Options. See Table 3-25.
Byte 2..8 Reserved
Table 3-25 - Options for Command 0x17
7 6
N/A N/A
N/A N/A
Reset
Options
N/A N/A
N/A N/A
RFU X X

3.4.21 Command 0x1A - Request Device Information

This command requests information about the device. Use this command in Set mode first to specify the
information to retrieve, then use Get mode to retrieve the requested information.
DynaPro Mini| PIN Encryption Device | Programmer's Manual (Commands)
6 5
Byte 1 Usage
5 4 3
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
X X X
Page 50 of 128 (D99875629-43)
4 3 2
2 1 0
N/A 0 0
N/A 0 1
N/A 1 0
N/A 1 1
X N/A N/A
1 0
Notes
Return Response ACK
(big data must exist),
Update, Reset when
Done
Return Response ACK
(big data must exist),
Update, Delayed
Response ACK, Allow
Reset later
RFU
Return Response ACK,
wait 100ms, Reset
Now (only valid after
successful update)
RFU
