3 - Command Set
Table 3-52 - Report 0x23 Track Status Byte When Using MS2.0 Masking (MS2.0 Only)
Value
0x00
0x01
0x02
0x03
0x04
0x05
0x06
0x07
0x08
0x09
0x0A
0x0B
0x0C
0x0D
0x0E
0x0F
0x10
0x11
0x12
0x13
0x14
0x15

3.5.5 Report 0x24 - PIN Response Report

This event is triggered by Command 0x04 - Request PIN Entry, which directs the device to send PIN
data to the host after a PIN is successfully entered.
The device may report 'Keypad Security' in Byte 1 to indicate the keypad has detected a tamper
condition. This can be triggered by a cardholder pressing a function key for too long when selecting an
account type. To cover this case, the software should include retry logic that resends Command 0x04 -
Request PIN Entry to re-arm the PIN pad.
Table 3-53 - Usage Table for Report 0x24
Bit 7
Byte 0 0x24
DynaPro Mini| PIN Encryption Device | Programmer's Manual (Commands)
Track Status If Using MS2.0
SUCCESS
N/A
NO_TK2_FS
BAD_TK2_PAN_LEN
NO_FIRST_TK1_FS
NO_SECOND_TK1_FS
NO_TK1_ES
NO_TK2_ES
TK1_TRAIL_TOO_SHORT
TK1_AND_TK2_PANS_NOT_EQUAL
BAD_TK1_FC
DATA_NOT_ASCII_DECIMAL
BAD_TK2_PAN_PREFIX
BAD_ADDITIONAL_DATA
TK1_LEN_TOO_LONG
DATA_PROHIBITED_CHARS
TK1_BLANK
TK1_ERROR
TK2_BLANK
TK2_ERROR
NOTRACKDATA
TK1_PANTOOSHORT
6 5
Page 63 of 128 (D99875629-43)
4 3 2 1 0
