3 - Command Set

3.5.8.1 Big Block Data for Authorization Request (ARQC)

In response to Command 0xA2 - Start EMV Transaction, when an ONLINE approval is required as
determined by the device and the ICC, by default the device will send EMV tag 70 containing an
authorization request message to the host in the format shown below. The list of tags the device will
include in the authorization request message can be re-configured by changing the list of tags stored in tag
DFDF02 (see Command 0xA1 - Access EMV Tags). The data will be contained in EMV tag 70.
Table 3-59 - Default ARQC Data Format
Tag
Secondary amount associated with the transaction
9F03
representing a cash back amount
Cryptogram returned by the ICC in response of
9F26
the GENERATE AC command
82 EMV Application Interchange Profile
5A EMV Application PAN
5F34 EMV Application PAN Sequence Number
9F36 EMV Application Transaction Counter
9F1A EMV Terminal Country Code
95 TVR
Authorized amount of the transactions (excluding
9F02
adjustments)
5F2A Transaction Currency Code
9A Local Date transaction was authorized
9C Transaction Type
9F37 Unpredictable Number
9F10 Issuer EMV Application Data
DFDF53 Fallback Indicator
F5 Container For Encrypted PIN
F4 Container For Encrypted MSR

3.5.9 Report 0x2A - Delayed Response ACK

This event is triggered by completion of longer-running commands that need to report status back to the
host. It is an asynchronous version of Command 0x01 - Response ACK.
Table 3-60 - Usage Table for Report 0x2A
Bit 7
Byte 0 0x2A
Status of Command ("ACKSTS")
Byte 1
Byte 2 ID for Command reporting status
DynaPro Mini| PIN Encryption Device | Programmer's Manual (Commands)
Description
6 5 4
Page 66 of 128 (D99875629-43)
Source Format
Device n
Card b
Card b
Card c
Card n
Card b
Device n
Device b
Device n
Device n
Device n
Device n
Device b
Card b
Device n
Device b
Device b
3 2
Length
6
8
2
0-10
1
2
2
5
6
2
3
1
4
0-32
1
Var
Var
1 0
