Magtek DynaPro Mini Programmer's Manual page 52

3 - Command Set
Bit 7
"V=4,SC=1,SR=1,TR=1,MS2=1,PFK=1,UDE=2,CE=2,CLE=1,DR=1" (null
terminated string)
Capability String Code Description:
V = Device Type
SC = Signature Capture Support, 1=Supported, 0=Not Supported
SR = SRED, 1=SRED, 0=NON-SRED
Byte 2..63
TR = Token Reversal Support, 1=Supported, 0=Not Supported
MS2 = MagneSafe 2.0 Support, 1=Supported, 0=Not Supported
PFK = PIN Fixed Key Support, 1=Supported, 0=Not Supported
UDE = Cardholder Data Entry Mode, 1=Encrypted Only, 2=Clear Text and Encrypted
CE = Contact EMV Level Support, 1=L1, 2=L2
CLE = Contactless EMV Level Support, 1=L1, 2=L2
DR = Delayed Response Support, 1=Supported, 0=Not Supported
Table 3-30 - Usage Table for Command 0x1A - Manufacturer
Bit 7
Byte 0 0x1A
Byte 1 0x03
"MagTek, Inc." (null terminated string)
Byte 2..63
Table 3-31 - Usage Table for Command 0x1A - Product Name
Bit 7
Byte 0 0x1A
Byte 1 0x04
The product name is a null-terminated string containing "DynaPro Mini"
Byte 2..63
Table 3-32 - Usage Table for Command 0x1A - Serial Number
Bit 7
Byte 0 0x1A
Byte 1 0x05
"12345678" (null terminated string)
Byte 2..63
Table 3-33 - Usage Table for Command 0x1A - Firmware Number
Bit 7
Byte 0 0x1A
Byte 1 0x06
DynaPro Mini| PIN Encryption Device | Programmer's Manual (Commands)
6 5
6 5
6 5
6 5
6 5
Page 52 of 128 (D99875629-43)
