Magtek DynaPro Mini Programmer's Manual page 39

3 - Command Set
Bit 7
Device Control 2 (default value = 0x00)
Bit 0 Allow Charging in iPod Accessory Protocol (iAP) mode (30-pin Only)
Configure charging mode
0 = Disable (default)
1 = Enable
Bit 1 MAC checking control for inbound online response (EMV Only)
Configure MAC requirement on inbound online response for Command 0xA4 - Acquirer
Response ARPC (MAC-MSR):
Byte 2 0 = Enable (default)
1 = Disable
Bit 2 Financial + ICC Card Type Reporting:
Configure Financial+ICC Card type reporting
0 = Enable (default)
1 = Disable
Bit 3 ARQC and Batch Data Output Format(Protected):
0 = DynaPro Format (default)
1 = Reserved For Future Use
Mask Configuration (default value = 0xC0, all enabled except MS2.0)
ISO Mask
Byte 3
0 = Disable
1 = Enable
MSR Card Configuration (default value = 0xD5, all enabled)
AAMVA
Byte 4
Card
0 = Disable
1 = Enable
Mask Character (factory setting is 0x30 representing ASCII '0')
Byte 5
Leading length to leave unmasked
In SRED, maximum length = 6
Byte 6 MS2.0 Only: When the device is configured to use
MagneSafe MS2.0 format, values greater than 8 are
interpreted as 8; values less than 5 are interpreted as 5
EMV L2 ICS Configuration (Default = 0x01)
Byte 7
Note: This setting is ignored when EMV Mode is disabled.
DynaPro Mini| PIN Encryption Device | Programmer's Manual (Commands)
6 5
MS2.0 Enable
Check Digit
00 = MS2.0 Disabled
0 = Disable
MS2.0 Only:
1 = Enable
10 = MS2.0 Enabled
Track 3 Data
Non-finance 00 = Disabled
card option 01 = Enabled
11 = Required
Page 39 of 128 (D99875629-43)
4 3 2
MS2.0 Only:
Track 2 Data
Error Blank
Track 2 Data
00 = Disabled
01 = Enabled
11 = Required
Trailing length to leave unmasked
In SRED, maximum length = 4
Ignored in MS2.0 format
1 0
MS2.0 Only:
Track 1 Data
Error Blank
Track 1 Data
00 = Disabled
01 = Enabled
11 = Required
