Appendix F - Error Codes
Appendix F
F.1

H Codes

Table 3-78 - "H" Error Codes
Code
Displayed
H1 Internal SYSCLK error
H2 Internal GPIO error
H3 Internal RNG error
H4 Internal RTC error
H5 Internal Timer Init failed
H6 Crypto Engine Init failed
H7 Internal SRAM test failed
H8 Crypto Library Init failed
H9 HAL Library Init failed
H10* Crypto Library Self-Test failed
H11* Firmware Signature Check error
H15 Keypad Controller Init failed
Unable to communicate with MSR or
H16
mismatched key
SDRAM, Touch Panel, Flash, K2 power-up
H17
failure
H18 iOS Security Chip Failure
H19 AMS 3911 Failure
H20 GPIO Extender Failure
H21 Battery Charge Measurement Failure
H22 ADC Failure
DynaPro Mini| PIN Encryption Device | Programmer's Manual (Commands)
Error Codes
Description
Page 112 of 128 (D99875629-43)
Comments
USIP bad
USIP bad
USIP bad
USIP or RTC crystal bad
USIP bad
USIP bad
USIP bad
USIP bad or flash programming failed
USIP bad
USIP bad or flash programming failed
FW contents tampered with or failed
Cirque controller or device SPI is bad
MSR, SPI, or cable bad
Peripheral or electronic switch bad
I2C bad
Communications with AMS chip failed
GPIO Extender Circuit bad
Battery Charge Measurement Circuit bad
USIP bad
