11.2 Quickstart guide for synchronous motors

smartphone
INVERTERapp
installation
Option: Bluetooth stick (BT/M12)
art. no. 10447294
Motor current
33.031
Motor rating
33.032
Motor speed
33.034
Motor frequency
33.035
Motor voltage
33.110
Motor
identification
Motor data is
being calculated
n controller
34.090 / 34.091
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Adapt drive controller to
motor and secure
Disassemble drive
controller cover
Mains connection L1, L2, L3, PE
terminals 1 – 4 on X1
Activate grid
Communication
Handheld
controller
Option: MMI (RJ9/M12)
art. no. 10004768
Drive type
33.010
synchronous motor
Enable software
Start-up protection
1.131
+24V on Dig In1
Target value
source
1.130
Internal
Fixed nominal
values
PC
INVERTERpc
installation
Option: Connection cable (USB/M12)
art. no. 10023950
1.132 set to
inactive
External
