BONFIGLIOLI DGM MPM Technical Manual page 13

Sizes C - D
Inver Type
DGN-MPM
Recommended motor rating
PT10 5.50 kW
PT11 7.50 kW
PT51 11.00 kW (Low duty)
PT12 11.00 kW
PT13 15.00 kW
PT14 18.50 kW
PT15 22.00 kW
PT55 30.00 kW (Low duty)
Power-conducting plate – Brake chopper
BC01 Without brake chopper
BC02 With brake chopper
MS00
MS90
DGM-MPM PTxx BCxx MSxx
* ETHERNET = ProfiNET + EtherCAT + ETHERNET/IP + SERCOS
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Application PCB – I/0 Support
With I/O support Module
Without I/O support Module
Housing type – External lid
EL01 Passive cooling + Potentiometer
EL02 Passive cooling
EL06 Active cooling + Potentiometer
EL09 Active cooling
EL44 Passive cooling + Brake chopper + internal Brake resistor + Potentiometer
EL45 Passive cooling + Brake chopper + internal Brake resistor
EL52 Passive cooling, Phoenix Quickon, 2x M12 I/O + Potentiometer
EL53 Passive cooling, Phoenix Quickon, 2x M12 I/O
EL56 Passive cooling, Phoenix Quickon, 2x M12 I/O + Brake chopper + internal Brake resistor + Potent.
EL57 Passive cooling, Phoenix Quickon, 2x M12 I/O + Brake chopper + internal Brake resistor
EL61 Active cooling + Brake chopper + internal Brake resistor + Potentiometer
EL62 Active cooling + Brake chopper + internal Brake resistor
EL63 Active cooling, 2x M12 I/O + Potentiometer
EL64 Active cooling, 2x M12 I/O
EL65 Active cooling, 2x M12 I/O + Brake chopper + internal Brake resistor + Potentiometer
EL66 Active cooling, 2x M12 I/O + Brake chopper + internal Brake resistor
Cover type
CV01 Without cover variant
CV05 Display and Man machine interface
CV11 Main switch
CV15 Main switch + Display and Man Machine Interface
Optional module – Brake rectifier module
BR00 Without rectifier module
BR10 Without rectifier module + Main switch
BR13 Rectifier module for FD brake + Main switch (Not with ETHERNET fieldbus)
BR30 Rectifier module for FD brake
IU00
IU01
IU03
IU13
IU23
IU33
ELxx CVxx BRxx IUxx
IO module
Without IO module
IO module
I/O Module + M12 MMI plug
I/O Module + M12 MMI plug + STO
I/O Module + M12 MMI plug + ETHERNET*
I/O Module + M12 MMI plug + ETHERNET* + STO
A B
X
X
X
X
X
X
X
X
A B
X X
X X
A B
X X
X X
A B
X
X
X X
X X
X
X
X
X
X
X
X X
X X
X
X
X
X X
A B
X X
X X
X X
X X
A B
X X
X X
X X
X X
A B
X X
X X
X X
X X
X X
X X
