General information
1.2.2

Warning symbols used

Symbol Meaning
Danger
Danger due to electrical shock and
discharge
Danger due to electromagnetic fields
1.2.3

Signal words

Signal words are used to identify the severity of the
danger.
DANGER
Indicates a direct hazard with a high level of risk, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a hazard with a moderate level of risk, which, if
not avoided, will result in death or serious injury.
CAUTION
Indicates a hazard with a low level of risk, which, if not
avoided, may result in minor or slight injury or property
damage.
1.2.4

Information notes

Information notes contain important instructions for the
installation and problem-free operation of the drive
controller. These must be followed at all times. The
information notes also point out that failure to observe
instructions may result in damage to property or financial
loss.
IMPORTANT INFORMATION
The drive controller may only be assembled, operated,
maintained and installed by trained and qualified staff.
Fig. 2: Example of an information note
6
Symbols within the information notes
Other notes
Symbol

1.3 Symbols used in this manual

Symbol
1., 1., 3.
...
➔
✓
◼
Fig. 3: Symbols and icons used
Abbreviations used
Abbreviation
Tab.
Fig.
It.
Ch.
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Symbol Meaning
Important information
Damage to property possible
Meaning
INFORMATION
Enlarged view
Meaning
Consecutive steps in a handling
instruction
Effect of a handling instruction
Final result of a handling instruction
List
Explanation
Table
Figure
Item
Chapter
