Parameter
1.132
Relationship to
parameter:
1.131
Selection of behaviour in response to enabling software (parameter 1.131).
No effect if autostart was selected.
0 = immediate start with high signal at input of control enable
1 = start only with rising edge at input of control enable
2 = digital input 1 (function active with high signal)
3 = digital input 2 (function active with high signal)
4 = digital input 3 (function active with high signal)
7 = analogue input 1 (must be selected in parameter 4.030)
1.133
Relationship to
parameter:
As well as enabling the software, the parameter can be used to parameterise another input for the free shutdown. When
the input is switched off, the output stages are shut down and the motor spins. The function runs regardless of software
enabling.
0 = no free shutdown
1 = digital input 1
2 = digital input 2
3 = digital input 3
1.150
Relationship to
parameter:
1.131
4.030
4.030
Selection of direction of rotation specification
0 = dependent on target value (depending on the plus or minus sign of the target value:
positive: forwards; negative: backwards)
1 = forwards only (no change in direction of rotation possible)
2 = backwards only (no change in direction of rotation possible)
3 = digital input 1 (0 V = forwards, 24 V = backwards)
4 = digital input 2 (0 V = forwards, 24 V = backwards)
5 = digital input 3 (0 V = forwards, 24 V = backwards)
8 = analogue input 1 (must be selected in parameter 4.030)
13 = virtual output (4.230)
1.180
Relationship to
parameter:
1.181
1.182
Selection of the source for error acknowledgement.
Errors can only be acknowledged once the error is no longer present.
Auto acknowledgement via parameter 1.181.
0 = manual acknowledgement not possible
1 = rising flank at digital input 1
2 = rising flank at digital input 2
3 = rising flank at digital input 3
5 = foil keypad (Ackn key)
6 = analogue input 1 (must be selected in parameter 4.030)
56
Start-up protection
Transfer status:
2
Free shutdown
Transfer status:
2
Rotation direction
Transfer status:
2
Acknowledge function
Transfer status:
2
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Unit: integer
min.:
0
Own value (to be entered!)
max.:
8
def.:
1
Unit: integer
min.:
0
Own value (to be entered!)
max.:
3
def.:
0
Unit: integer
min.:
0
Own value (to be entered!)
max.:
16
def.:
0
Unit: integer
Own value (to be entered!)
min.:
0
max.:
7
def.:
4
