3.4.10 Basic fieldbus integrated on DGM Modular

Fig. 20: Basic fieldbus integrated on DGM Modular
Pin assignment of interfaces for M12 socket for Modbus
Socket
It.
1
Fig. 21: Round plug connector, 4-pin, M12, A-coded for Modbus fieldbus
Pin assignment of interfaces for M12 plug for CANopen
Plug
It.
2
Fig. 22: Round plug connector, 5-pin, M12, A-coded for CANopen fieldbus
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
JST 4 poles RS485
Pin no.
1
2 RS 485 - A
3
4 RS 485 - B
Housing Shielding
JST 3 poles CANopen
Pin no.
1 Not assigned
2 Not assigned
3 CAN_GND
4
5
Housing Shielding
Signal Material ID
n. c.
GND
YP00020445
Signal Material ID
YP00021591
CAN_H
CAN_L
