4.152 / 4.172
Relationship to
parameter:
4.150 / 4.170
If the set process variable exceeds the switch-off limit, the output is again set to 0.
5.3.6

Virtual output

The virtual output can be parameterised like a relay and is available as an option with the following parameters:
1.131 Software enable / 1.150 Direction of rotation / 1.054 Ramp selection /
5.090 Parameter set change / 5.010 + 5.011 External error 1 + 2
4.230
Relationship to
parameter:
1.054
1.131
1.150
4.231 Selection of the process variable to which the output should switch.
4.232
5.010 / 5.011
5.090
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Dox off
Transfer status:
2
VO function
Transfer status:
2
0 = Not used
1 = Intermediate circuit voltage
2 = Supply voltage
3 = Motor voltage
4 = Motor current
5 = Actual frequency value
6 = -
7 = -
8 = IGBT temperature
9 = Inner temperature
10 = Error (NO)
11 = Error inverted (NC)
13 = Digital input 1
14 = Digital input 2
15 = Digital input 3
17 = Ready for operation (mains supply on, no HW enable, motor stationary)
18 = Ready (mains supply on, HW enable set, motor stationary)
19 = Operation (mains supply on, HW enable set, motor running)
20 = Ready for operation + Ready
21 = Ready for operation + Ready + Operation
22 = Ready + Operation
23 = Motor rating
24 = Torque
25 = Fieldbus
26 = Analogue input 1
32 = Target frequency value after ramp
33 = Target frequency value
34 = Actual speed value
35 = Actual frequency value sum
36 = Torque sum
37 = Target frequency value after ramp sum
38 = Target frequency value sum
39 = Actual speed value sum
50 = Motor current limit enabled
Nominal-actual comparison (para. 6.070 – 6.071)
51 =
Unit:
min.: - 32767 Own value (to be entered!)
max.: 32767
def.: 0
Unit: integer
Own value (to be
min.: 0
entered!)
max.: 51
def.: 0
