Overview of the drive controller

2. Overview of the drive controller

2.1 Model description

Sizes A - B
Inver Type
DGN-MPM
Recommended motor rating
PT03 0.55 kW
PT04 0.75 kW
PT05 1.10 kW
PT06 1.50 kW
PT46 2.20 kW (Low duty)
PT07 2,20 kW
PT08 3.00 kW
PT09 4.00 kW
PT49 5.50 kW (Low duty)
Power-conducting plate – Brake chopper
BC01 Without brake chopper
BC02 With brake chopper
MS00
MS90
DGM-MPM PTxx BCxx MSxx
* ETHERNET = ProfiNET + EtherCAT + ETHERNET/IP + SERCOS
12
Application PCB – I/0 Support
With I/O support Module
Without I/O support Module
Housing type – External lid
EL01 Passive cooling, potentiometer
EL02 Passive cooling
EL44 Passive cooling + Brake chopper + internal Brake resistor + Potentiometer
EL45 Passive cooling + Brake chopper + internal Brake resistor
EL50 Passive cooling, Harting, 2x M12 I/O + Potentiometer
EL51 Passive cooling, Harting, 2x M12 I/O
EL52 Passive cooling , Phoenix Quickon, 2x M12 I/O + Potentiometer
EL53 Passive cooling , Phoenix Quickon, 2x M12 I/O
EL54 Passive cooling, Harting, 2x M12 I/O + Brake chopper + internal Brake resistor + Potentiometer
EL55 Passive cooling, Harting, 2x M12 I/O + Brake chopper + internal Brake resistor
EL56 Passive cooling, Phoenix Quickon, 2x M12 I/O + Brake chopper + internal Brake resistor + Potent.
EL57 Passive cooling , Phoenix Quickon, 2x M12 I/O + Brake chopper + internal Brake resistor
Cover type
CV01 Without cover variant
CV05 Display and Man machine interface
CV11 Main switch
CV15 Main switch + Display and Man Machine Interface
Optional module – Brake rectifier module
BR00 Without rectifier module
BR10 Without rectifier module + Main switch
BR13 Rectifier module for FD brake + Main switch (Not with ETHERNET fieldbus)
BR30 Rectifier module for FD brake
IU00
IU01
IU03
IU13
IU23
IU33
ELxx CVxx BRxx IUxx
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
IO module
Without IO module
IO module
I/O Module + M12 MMI plug
I/O Module + M12 MMI plug + STO
I/O Module + M12 MMI plug + ETHERNET*
I/O Module + M12 MMI plug + ETHERNET* + STO
