Parameter
System- specific settings
For load applications performed vertically with a controlled motor operation (crane or lifting applications), a value of 10
(vertical drive/lifting application) should be set in parameter 37.020.
During the start-up phase, this setting activates a servo control during which the holding torque is always built up first in a
positive target value direction. To ensure a jolt-free start, this direction must always be against gravity. In V/f mode,
deactivate the servo control using the value 20.
During horizontal movement (conveyor belt or linear conveyance of load) a value of 20 should be set in parameter
37.020. In such cases, servo control is always undertaken in a direction of motion dependent on the current target value.
A holding torque is also built up.
With rotating machines, "0" should be entered for the br. closing and br. opening time. No holding torque is then built up
and the machine can start and stop freely.
37.010
Relationship to
parameter:
Selection of an input for manually activating the brake module
0 = disable
1 = digital input 1
2 = digital input 2
3 = digital input 3
4 = digital input 4
5 = analogue input 1
6 = analogue input 2
7 = fieldbus (via bit 8 in process variable 0x9c Dig Outs)
8 = customer PLC
9 = virtual output
20 = digital input 1 + HW enable / STO
21 = digital input 2 + HW enable / STO
22 = digital input 3 + HW enable / STO
23 = digital input 4 + HW enable / STO
24 = analogue input 1 + HW enable / STO
25 = analogue input 2 + HW enable / STO
26 = fieldbus (via bit 8 in process variable 0x9c Dig Outs) + HW enable / STO
27 = customer PLC + HW enable / STO
28 = virtual output + HW enable / STO
80
Manual brake activation
Transfer status:
1
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Unit: integer
min.: 0 Own value (to be
entered!)
max.: 30
def.: 0
