Parameter
4.231
Relationship to
parameter:
4.230
If the set process variable exceeds the switch-on limit, the output is set to 1.
4.232
Relationship to
parameter:
4.230
If the set process variable exceeds the switch-off limit, the output is again set to 0.
4.233
Relationship to
parameter:
4.234
Specifies the length of the switch-on delay.
4.234
Relationship to
parameter:
4.233
Specifies the length of the switch-off delay.
4.235
Relationship to
parameter:
4.230
This parameter can be used to invert the virtual output.
0 = disable
1 = enable
5.3.7
External error
5.010 / 5.011
Relationship to
parameter:
4.110 / 4.113
4.230
Selection of source via which an external error can be reported.
If there is a high signal at the selected digital input, the drive controller with error no.
23 / 24, switches external error ½.
Parameters 4.110 to 4.113 Dix inverse can be used to invert the logic of the digital input.
62
VO-On
Transfer status:
2
VO-Off
Transfer status:
2
VO-On delay
Transfer status:
2
VO-Off delay
Transfer status:
2
VO inverted
Transfer status:
2
External error 1/2
Transfer status:
2
0
=
Not used
1
=
Digital input 1
2
=
Digital input 2
3
=
Digital input 3
5
=
Virtual output (parameter 4.230)
6
=
Analogue input 1 (must be selected in parameter 4.030)
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Unit:
min.: - 32767
Own value (to be entered!)
max.: 32767
def.:
0
Unit:
min.: - 32767
Own value (to be entered!)
max.: 32767
def.:
0
Unit: s
min.:
0
Own value (to be entered!)
max.:
10000
def.:
0
Unit:
min.:
0
Own value (to be entered!)
max.:
10000
def.:
0
Unit: integer
min.:
0
Own value (to be entered!)
max.:
1
def.:
0
Unit: integer
min.:
0
Own value (to be entered!)
max.:
7
def.:
0
