Digital Inputs - BONFIGLIOLI DGM MPM Technical Manual

Parameter
4.034
Relationship to
parameter:
4.033
4.035
Selection of the lower limit of a physical value to be displayed.
4.035 / 4.065
Relationship to
parameter:
4.033
4.034
Selection of the upper limit of a physical value to be displayed.
4.037
Relationship to
parameter:
The signal of the analogue input can be inverted here.
0 = disable (example: 0 V = 0 %
1 = enable (example: 0 V = 100 % 10 V = 0 %)
5.3.4

Digital inputs

4.110 to 4.112
Relationship to
parameter:
This parameter can be used to invert the digital input.
0 = disable
1 = enable
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Ai1 physical minimum
Transfer status:
2
Ai1 physical maximum
Transfer status:
2
Ai1 inverted
Transfer status:
2
10 V = 100 %)
DIx inverted
Transfer status:
2
Unit:
Own value (to be entered!)
min.: - 10000
max.: + 10000
def.: 0
Unit:
Own value (to be entered!)
min.: - 10000
max.:+ 10000
def.: 100
Unit: integer
min.: 0 Own value (to be entered!)
max.: 1
def.: 0
Unit: integer
min.: 0 Own value (to be entered!)
max.: 1
def.: 0
