Overview of the drive controller

2.2 Scope of delivery

2.2.1

Sizes A-C

Compare the scope of delivery of your product with that
provided below.
Fig. 6: Scope of delivery
Key
Drive controller article number
1 Drive controller (variant)
Adapter plate with terminal
2
(not part of the scope of delivery)
3 Seal (not part of the scope of delivery)
Adapter plate article number
Motor
4
(not part of the scope of delivery)
5 Operating manual
14
2.2.2
Fig. 7: Scope of delivery, size D
Key
Drive controller article number
1
2
3
4
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN

Size D

Drive controller (variant)
Cup
Poly bag containing seals, screws and shims
Operating manual
