2WD/AWD Shift Lever
5332M-0402-170E

Locking Differential

Differential can be locked to minimize slipping o slippery surface.
• Always stop machine to operate differential lock lever. Operating differential
lock lever while machine is in motion can damage differential.
• Keep differential lock in [OFF] position under normal running condition.
Differential may be damaged.
• Do not turn machine when differential lock is in [ON] position.
Differential Lock Lever
5332M-0402-180E
Operation
1. Stop machine.
2. Move 2WD/AWD shift lever to [2WD] or
[AWD] position firmly.
1. Move differential lock lever to [ON] position.
2. Move auxiliary transmission shift lever to [L
(low speed)] position.
3. Drive slowly out of the slippery area.
-31-
