Adjusting Drive Pedal - CanyCom MASAO CMX 2502 Operator's Manual

4
Seat Switch Bracket
Bolts
5335M-0401-010E

Adjusting Drive Pedal

• Always check if the drive pedal is fixed firmly after adjusting.
Drive Pedal
5332M-0401-100E
Operation
3.
4.
5.
1.
Pedal (Forward)
2.
NOTE
• Drive pedal can be adjusted in 3 positions
Bolts
Remove 2 bolts fixing seat switch bracket.
Move seat switch bracket into desired
position and fix with bolts firmly.
Pull safety pin back and lower the seat.
Remove two bolts fixing forward pedal with
drive pedal.
Adjust the pedal (forward) into the desired
position and fix with bolts.
and angle.
-22-
