ATTENTION: park the machine in an enclosed place, on a flat and level surface; near the machine there must be no objects that could
either damage it, or be damaged through contact with it.
ATTENTION: the room used to recharge the batteries must be adequately ventilated to prevent the accumulation of gases that leak from
batteries.
3. Unhook the tank rotation stop lever (8) (Fig.9) and turn the recovery tank to its maintenance position (Fig.10).
A. Recharging the batteries without the built-in battery charger:
• Disconnect the battery connector from the machine's main system connector (Fig.11).
ATTENTION: the following operations must be carried out by qualified personnel. An incorrect connection of the connector may cause a
malfunction of the device.
• Connect the external battery charger cable to the battery connector.
N.B.: the coupling connector of the battery charger is consigned inside the bag containing this instruction booklet, and must be assembled
on the cables of the battery charger as indicated in the instructions.
ATTENTION: before connecting the batteries to the battery charger, make sure it is suitable for the batteries used.
N.B.: carefully read the use and maintenance instructions of the battery charger that is used for charging.
CAUTION: keep the recovery tank open for the duration of the battery recharging cycle to allow gas fumes to escape.
• Once the recharge cycle has been completed, disconnect the battery charger's cable from the battery connector.
• Connect the battery connector to the machine's main system connector.
• Rotate the recovery tank into the working position (Fig.12). User the lever (8) to block its rotation (Fig.13).
B. Recharging the batteries with the built-in battery charger:
ATTENTION: the following operations must be carried out by qualified personnel. An incorrect connection of the connector may cause a
malfunction of the device.
N.B.: carefully read the use and maintenance instructions of the battery charger that is used for charging.
• Plug the battery charger cable into the mains socket.
• Connect the battery charger power cable with the cable on the battery charger itself.
CAUTION: before connecting the batteries to the battery charger, make sure it is suitable for the batteries used.
N.B.: the battery charger power cable is delivered inside the bag containing this instruction booklet.
CAUTION: keep the recovery tank open for the duration of the battery recharging cycle to allow gas fumes to escape.
• When the recharge cycle is complete, disconnect the battery charger supply cable from the cable on the battery charger itself.
• Rotate the recovery tank into the working position (Fig.12). Use the lever (8) to block its rotation (Fig.13).

FILLING THE SOLUTION TANK WITH WATER

Before filling the solution tank, carry out the following steps:
1. Take the machine to the usual place for filling the solution tank.
2. Carry out the steps necessary to secure the machine, see paragraph "MACHINE SAFETY" on page 15.
3. Make sure the solution tank drainage cap (9) is closed; if it isn't, close it (Fig.14).
4. Make sure the water system filter cap (10), on the front left-hand side of the machine, is closed; if it isn't, close it (Fig.15).
5. Fill with clean water, at a temperature no higher than 50°C (122°F) and no lower than 10°C (50°F).
6. Check the water level via the tube (11) underneath the operator's seat (Fig.16).
The tank can be filled with water in the following ways:
A) filling through the side inlet:
• Remove the cap (12) on the side of the machine (Fig.17), and fill the solution tank using a hose or bucket.
• Before filling the tank, check that the filter (13) is correctly positioned above the filler opening (Fig.17).
B) filling through the quick filling pipe:
