SIDE STAND INDICATOR/SWITCH

For the safety of the customer a side stand
indicator (1) is provided.
A side stand switch (2) is provided in the side
stand, when the vehicle is parked on side stand
(Ignition switch "ON"), the switch enables the
side stand indicator lamp to glow on the
speedometer panel.
1
(1) Side stand indicator
(2) Side stand switch
2

FUEL TANK

Fuel tank capacity is 9.8 litres (Be sure to fill
the fuel tank when fuel gauge needle enters
red band).
To remove the fuel tank cap (1), insert the
•
ignition key (2), turn it anti-clockwise and
lift the lid (3) as shown in the picture.
Remove the cap by turning it anti-
•
clockwise.
2
(1) Fuel tank cap (2) Ignition key (3) Lid
5
(4) Fuel
18
3
1
4
(5) Filler neck
