HERO SPLENDOR+ PROGRAMMED FI Manual page 37

3
1
2
(1) Left side cover
(3) Lug
5
(5) Air cleaner cover screws
(6) Air cleaner cover
Remove the air cleaner element (7)
•
from air cleaner housing (8).
4
(2) Side cover screw
(4) Direction indicator
8
(7) Air cleaner element
(8) Air cleaner housing
! !
Never wash or clean the viscous filter.
•
Replace filter element once in every 15000
km.
Replace it earlier if it becomes very dirty,
•
6
damage on surface or on the sealing area.
34
CAUTION
7
