Vehicle Views - HERO SPLENDOR+ PROGRAMMED FI Manual

TOP VIEW
6
5
4
3
2
1
(1) Turn signal indicator
(2) Side stand indicator
(3) Horn switch
(4) Turn signal lamp switch
(5) Clutch lever
(6) Rear view mirror
(7) Headlamp dimmer switch
(8) Odometer
(9) Speedometer
(10) i3s indicator
(11) Neutral indicator
*Accessories and features shown may not be part of standard fitment.

VEHICLE VIEWS

7 8 9 10 11
(12) Programmed FI malfunction indicator
(13) Fuel gauge
(14) High beam indicator
(15) i3s switch
(16) Front brake lever
(17) Throttle grip
(18) Electric starter switch
(19) Ignition switch with steering lock
(20) Fuel tank lid
(21) Leg guard
2
12 13 14 15
lamp (MIL)
16
17
18
19
20
21
