PARTS FUNCTION

Ignition switch

"OFF"( )
position/
Lock open
"LOCK" position
Key position
The engine can be started, turn signal lamps,
horn, tail/stop lamp can be operated.
Fuel gauge will be functional. Programmed FI
"ON" ( )
malfunction indicator lamp (MIL) illuminates.
i3s indicator glows for 2 seconds.
Engine cannot be started and no electrical
"OFF"( )
system will be functional.
"LOCK"
Steering can be locked.
"ON" ( )
position
3
1. Ignition switch
2. Ignition key
3. Steering lock position
Function
12
2
Key removal
Key cannot be removed
Key can be removed
Key can be removed
