RIGHT SIDE VIEW
14
15
(1) Pillion footrest
(2) Battery compartment (Inside)
(3) Kick starter pedal
(4) Rider footrest
(5) Starter motor
*Accessories and features shown may not be part of standard fitment.
13
2 3
1
4
(6) Rear brake pedal
(7) Oil level dipstick
(8) Utility box
(9) Front suspension
(10) Headlamp
12
5
7
8
(11) Front visor
(12) Fuel tank
(13) Seat
(14) Rear shock absorber
(15) Exhaust muffler
4
11
10
9
